Extron electronics FOX3 T 301 PC Setup Manual

FOX3 T 301 PC, FOX3 T 311 PC,
and FOX3 T 201 PC • Setup Guide
The Extron FOX3 PowerCage Fiber Optic Transmitters are modular, compact single slot boards for the Extron PowerCage 411
that transmit lossless 4K @ 60 Hz video, audio, RS-232 control, and USB HID and USB 2.0 over fiber. This guide provides
instructions for an experienced installer to install and operate the devices.
WARNING:
The FOX3 PC transmitters output continuous invisible light (Class 1 rated), which may be harmful to the
eyes; use with caution. Plug the attached dust caps into the optical transceivers when the fiber cable is unplugged.
CLASS 1 LASER PRODUCT, see the PowerCage 411 Series User Guide, at www.extron.com.
AVERTISSEMENT :
être dangereux pour les yeux, à utiliser avec précaution. Branchez les protections contre la poussière dans l'ensemble
émetteur/récepteur lorsque le câble fibre optique est débranché.
Produit laser de classe 1, voir le PowerCage 411 Series User Guide sur
Installation
Board Installation
Install the transmitter into a PowerCage 411 enclosure as
required.
ATTENTION:
•
Use ESD precautions when installing a board to
avoid damaging it. Keep the board in the anti-static
bag until it is needed. Use proper grounding
techniques during installation.
•
Prenez les précautions ESD lorsque vous installez
une carte afin d'éviter de l'endommager. Gardez la
carte dans le sachet dépoussiérant jusqu'à ce que
vous en ayez besoin. Utilisez des techniques de mise
à la terre correctes pendant l'installation.
NOTES:
•
FOX3 endpoints are not backwards compatible with FOX or FOX II endpoints.
•
A FOX3 endpoint with a LinkLicense cannot pass uncompressed 4K @ 60 Hz video signal to a FOX3 endpoint without
the LinkLicense.
•
PowerCage boards are hot-swappable.
•
Ensure the boards are flush with the rear of the enclosure and the screws are tightened securely before applying power.
•
Each slot is independent from other slots. The type of board installed in a slot or the order of slots filled does not impact
boards installed in other slots.
1.
If applicable, remove any blank plates or previously installed boards from the PowerCage 411 enclosure to fit the board.
2. With the ports facing away from the PowerCage 411 enclosure and the screws positioned at the top, align the bottom board
edges with the posts of the desired slots on the PowerCage 411 enclosure.
3. Carefully slide the board into the slot and push it firmly into place.
4.
Tighten the screws with a tool to secure the board to the enclosure.
Le FOX3 PC émetteur émet une lumière invisible en continu (conforme à la classe 1) qui peut
www.extron.com
B
A
IN
T
O U
IN
T
O U
T
O U
O P
.0 L O
B 2
U S
U T
ID 2
B H - 2 3 IN P
M I
U S R S
H D
IN
D IO
B
A U G
R x
T x
A
IN
T
O U
IN
T
O U
T
O U
O P
.0 L O
B 2
U S
U T Align board and
2
- 2 3 IN P
M I
R S
H D
G
R x
T x
slide into slot.
(en anglais).
B
A
IN
T
O U
IN
T
O U
T
O U
O P
.0 L O
B 2
U S
U T
ID - 2 3 2 IN P
B H
R S M I
U S
H D
IN
D IO
G
A U R x
T x
B
A
IN
T
O U
IN
T
O U
T
O U
O P
.0 L O
B 2
U S
U T
ID 2
B H - 2 3 IN P
M I
U S R S
H D
IN
D IO
A U G
R x
T x
Screws
(2 per board)
