6. Programming the decoder

You can program the configuration variables (CV) using a DCC digital
central unit. See the chapter in the manual of your central unit where
the byte wise programming of configuration variables (CVs) is
explained.
When using a Motorola central unit you can set the decoder address
with a programming
features is impossible with Motorola central units.

6.1. Programming decoder addresses

Addresses of the Multi-Decoder MD-2
Depending on the set operating mode, two or three consecutive
quadruple accessory decoder address blocks are assigned to each
decoder address.
Operating
mode 1
"Servos +
turnouts"
Operating
mode 2
"Servos +
push-buttons"
Page 22
push-button. Changing the other decoder´s
Connecting area
1
8 servos
8 servos
Connecting area
2
4 solenoid
accessories or
8 other
accessories
8 push-buttons
Multi-Decoder MD-2
Number of
accessory decoder
address blocks
3 blocks
(= 12 addresses)
2 blocks
(= 8 addresses)
