Hardware layout and configuration

The STM32 Nucleo-144 board is designed around the STM32 microcontrollers in a 144-pin
LQFP package.
Figure 3
push-buttons, LEDs, USB, Ethernet, ST Zio connectors and ST morpho headers).
Figure 4
The mechanical dimensions of the board are shown in
shows the connections between the STM32 and its peripherals (ST-LINK/V2-1,
and Figure 5 show the location of these features on the STM32 Nucleo-144 board.

Figure 3. Hardware block diagram

ST-LINK part
IO
B1
USER
RESET
B2
RST
MCU part
Micro-B
USB
connector
Embedded
ST-LINK/V2-1
IO
STM32
microcontroller
USB RMII
Micro-AB
RJ45
USB
connector
connector
UM1974 Rev 9
Hardware layout and configuration
Figure 6 and Figure 7.
LEDs
LD2/3
LED
LD1
MSv65798V1
