Hardware layout and configuration
Connector
CN10
1. For more details refer to
2. PA7 is used as D11 and connected to CN7 pin 14 by default, if JP6 is ON, it is also connected to CN9 pin
15 as COMP2_INP. In this case only one function of the Comparator input or D11 must be used.
3. PE2 is connected to both CN9 pin 14 (I/O) and CN10 pin 25 (I/O). Only one connector pin must be used at
one time.
44/85
Table 14. NUCLEO-F303ZE pin assignments (continued)
Pin
Pin Signal name
name
24 D40 TIMER_A_PWM2N
26 D39 TIMER_A_PWM3N
28 D38 TIMER_A_BKIN2
30 D37 TIMER_A_BKIN1
32 D36 TIMER_C_PWM2
34 D35 TIMER_C_PWM3
Table 12: Solder
UM1974 Rev 9
STM32
pin
PE10
PE12
PE14
PE15
PB10
PB11
bridges.
UM1974
Function Remark
TIM1_CH2N
TIM1_CH3N
TIM1_BKIN2
-
TIM1_BKIN1
TIM2_CH3
TIM2_CH4
