Hardware layout and configuration

The STM32U083C-DK Discovery kit is designed around the STM32U083MC microcontroller, in an LQFP80
package.
Figure 3 illustrates the connection between the STM32 and its peripherals (STLINK-V2EC, push-button, joystick,
touchkey, LEDs, temperature sensor, LCD segments, user USB, mikroBUS
connectors, and extension connectors).
Figure 4 shows the location of the STM32U083C-DKDiscovery kit features.
The mechanical dimensions of the board are shown in
USB Type-C
connector
UM3292 - Rev 1
Figure 3.
32 KHz crystal
®
STLINK-V2EC
STDC14
receiver
LEDs
Joystick
Reset button
Touchkey
™
Figure 5.
Hardware block diagram
1.8 to 3.3V
power supply
RTC LCD
VCP
USB
UART2
SWD
I2C1
STM32U083MCT6
GPIO
GPIO
TSC
UM3292
Hardware layout and configuration
®
connectors, ARDUINO
LCD segments
USB Type-C
connector
Temperature
sensor
mikroBUS
connectors
ARDUINO
connectors
Extension
connectors
®
TM
®
