MultiVOIP Quick Start Guide
3. Connect a network cable to the ETHERNET 10BASET
connector on the back of the MultiVOIP. Connect the other
end of the cable to your network.
4. If you are connecting a station device such as an analog
telephone, a fax machine, or a Key Telephone System
(KTS) to your MultiVOIP, connect one end of an RJ11
phone cord to the Voice/Fax Channel 1 FXS connector on
the back of the MultiVOIP and the other end to the station
device.
If you are connecting a PBX extension to your MultiVOIP,
connect one end of an RJ11 phone cord to the Voice/Fax
Channel 1 FXO connector on the back of the MultiVOIP
and the other end to the PBX extension.
If you are connecting an E&M trunk from a telephone
switch to your MultiVOIP, connect one end of an RJ45
phone cord to the Voice/Fax Channel 1 E&M connector
on the back of the MultiVOIP and the other end to the
trunk. Refer to the User Guide for E&M pin assignments.
If you are connecting to an E&M trunk, you need to ensure
that the E&M trunk jumper is in the correct position for the
E&M type trunk. The default E&M jumper position is E&M
type 2. To change the E&M jumper position, perform the
E&M jumper block positioning procedure, which
immediately follows this procedure.
5. Repeat the above step to connect the remaining telephone
equipment to each Voice/Fax Channel on your MultiVOIP.
6. Turn on power to the MultiVOIP by placing the ON/OFF
switch on the back panel to the ON position. Wait for the
BOOT LED on the MultiVOIP to go off before proceeding.
This may take a couple minutes.
Proceed to the next section to load the MultiVOIP software.
