Flow vision FC 01- CA User Manual page 48

Flow Meter | FC01- CA
• ERR. bargraph
(bar value outside measuring range)
• ERR. bargraph
(bar initial value ≥ bar final value)
The menu can only be quitted after correction of the error(s). To do this, return to the beginning
of the configuration menu by pressing ▲ UP or ▼ DOWN and select the menu option with the
incorrect entry for correction.
Caution!
If during the configuration data are affected which are accessible in the parameter selection
menu, (which may be the case for the options Sensor Selection, Medium Selection and limit
Switch Assignment), the option "PARAMETERS" in the main menu will be flashing.
In this event it is imperative to branch into parameter selection menu to set the data in
conformance with the desired application.
Changing the limit switch assignment from LS1 → F / LS2 → T to
Example:
LS1 → F / LS2 → F
Effects on
LS2 ON = 0.00
parameter data:
LS2 OFF = end of measuring range (depending on the medium selected)
Reason: Changing the physical assignment of limit switch 2 will adjust its switch-on and
switch-off values to the new assignment (flow rate).
An overview of the configuration menu and a summary of the measuring ranges and menus
available for the sensor type selected are shown on the following pages.
48
CONFIGURATION
OUT OF RANGE
ZERO ≥ FS
