2 . 1 .2 .2 Insertion head CSP for sensor adapter TP or ball valve BV

Application:
Style:
Installation:
Material of the area
exposed to medium:
retention slot
ø24
8
ø18
ø20
14
INSTALLATION
general industry and installation
insertion-type for sensor adapter TP-... and ball valve
sensor adapter TP-.. (fig. 5)
ball valve BV-.. (fig. 6)
stainless steel 1.4571/AISI 316 Ti, electropolished
O ring viton
O ring
O ring
sensor adapter TP-...
union nut
retention pin
monitoring head CSP-11..
fig. 4
