Air flow rate
Universal
Air flow rate
Single and
Low air flow rate
Connections
3) Pressure information: overpressure with respect to atmospheric
pressure

Operating

3)
50 l /min (at 1.4 bar ) for aeration
N
and ventilation
3)
150 l /min (at 6 bar ) for aeration
N
and double acting ventilation
Q = 100 l /min (according to
Nn N
definition with pressure drop from
7 to 6 bar absolute)
Q = 7 l /min (according to defnition
Nn N
with Single-acting pressure
drop from 7 to 6 bar absolute)
Internal thread G1/4"
7 OPERATING
7.1

Operating state

AUTOMATIC (AUTO)
Normal controller mode is implemented and monitored in AUTO-
MATIC operating state.
MANUAL
In MANUAL operating state the valve can be opened and closed
manually via the buttons.
To operate the DIP switches and buttons, make sure that
the local control lock is deactivated/unlocked (factory
setting): with communication software or fieldbus
communication.
DIP switch 4 can be used to switch between the two operating
states AUTOMATIC and MANUAL (see chapter "7.2.2 Function of
the DIP switches").
