6.5.2 Electrical data, IO-Link
Protection class
Connection
Port Class A
Operating voltage
Current consumption
Port Class B
Operating voltage
System supply (Pin 1+3)
Actuator supply (Pin 2+5)
2)
Current consumption
System supply (Pin 1+3)
Actuator supply (Pin 2+5)
Total power consumption
2) Actuator supply is galvanically isolated from the system supply in
accordance with IEC 60664 and for electrical safety in accordance with
SELV from IEC 61010-2-201
10
I II as per DIN EN 61140
(VDE 0140-1)
C ircular plug-in connector M12 x
1, 5-pin, A-coded
24 V DC ±25%
(according to specifications)
max. 150 mA
24 V DC ±25 %
(according to specification)
24 V DC ±25 %
(according to specification)
max. 50 mA
m ax. 120 mA
max. 3.5 W
english
Type 8791 REV.2
Technical data
6.5.3 Electrical data, büS
Protection class
Connection
Operating voltage
Current consumption
Total power consumption m ax. 3.5 W
6.6

Pneumatic data

Control medium N eutral gases, air
Quality classes in accordance with ISO
8573-1
Dust content C lass 7, max. particle size 40 µm, max.
particle density 10 mg/m³
Water content C lass 3, max. pressure dew point -20 °C
or min. 10 °C below the lowest operating
temperature
Oil content C lass X, max. 25 mg/m³
Temperature range 0 – +60 °C
Pressure range 1.4 – 7 bar
I II as per DIN EN 61140
(VDE 0140-1)
C ircular plug-in connector M12 x 1,
5-pin, A-coded
2 4 V DC ±25 %
(according to specification)
max. 150 mA
