6.9.100 ALARM 425, FPC Update Failure
Cause
This alarm is generated after the control card failed to update the fan power card PUD.

Troubleshooting

• Check the fan power card wiring.
• Replace fan power card.
• Contact supplier.
6.9.101 ALARM 426, FPC Config
Cause
The number of found fan power cards does not match the number of configured fan power cards. See parameter group 15-6* Option
Ident for the number of configured fan power cards.
Troubleshooting
• Check fan power card wiring.
• Replace fan power card.
6.9.102 ALARM 427, FPC Supply
Cause
Supply voltage fault (5 V, 24 V, or 48 V) on fan power card is detected.
Troubleshooting
• Check fan power card wiring.
• Replace fan power card.
6.9.103 ALARM 432, Inrush Mode Error
Cause
An Active Inrush card reported the wrong mode. The report value indicates which inrush card reported the alarm.
Troubleshooting
• Check inrush card wiring.
• Replace inrush card.
6.10 Troubleshooting
Table 21: Troubleshooting
Symptom Possible cause
Display dark/No Missing input power.
function
Missing or open fuses.
No power to the LCP.
Short circuit on control volt-
age (terminal 12 or 50) or at
control terminals.
Incompatible LCP (LCP from
VLT 2800 or
®
5000/6000/8000/ FCD or
FCM).
Wrong contrast setting.
64 | Danfoss A/S © 2023.01
Test
Check for loose connections.
See Open power fuses in this table
for possible causes.
Check the LCP cable for proper
connection or damage.
Check the 24 V control voltage sup-
ply for terminal 12/13 to 20–39, or
10 V supply for terminals 50–55.
–
–
Operating the Drive
Solution
Check the input power source.
Follow the recommendations provi-
ded.
Replace the faulty LCP or connection
cable.
Wire the terminals properly.
Use only LCP 101 (P/N 130B1124) or
LCP 102 (P/N. 130B1107).
To adjust the contrast, press [Status] +
[▲]/[▼].
