3 Product Overview
3.1 VLT® Ea4 Parallel Drive Modules Basic Kit
The VLT® Ea4 Parallel Drive Modules basic kit is used to create a drive system consisting of 4 drive modules. This kit provides a great-
er power range in a smaller enclosure, while allowing system integrators design flexibility and the potential to fabricate custom
components for the system.
The basic kit contains the following components:
•
Drive modules
•
Control shelf
•
Wire harnesses
•
DC fuses with microswitch connectors
3.2 Drive Modules
The VLT® Ea4 Parallel Drive Modules basic kit contains 4 drive modules which are used to convert AC mains input into a variable AC
waveform output.
1
2
3
4
5
6
7
8
Illustration 4: Drive Module Overview
