- Page 1 Data sheet Service guide Headline Myriad Pro Pressure relief valve max. 26/26 pt. and min. 18/18 pt. VRH 5 - 120 (F) max. 3 rows Disassembling and assembling hpp.danfoss.com © Danfoss | 2024.01 AX384036216157en-000103 | 1...
- Page 2 Service guide Disassembling and assembling VRH 5 - 120 (F) Table of Contents Contents Introduction 1. Disassembling 2. Assembling 3. Service kit liste for VRH 5 3.1 Exploded view VRH 5 4. Service kit liste for VRH 30 4.1 Exploded view VRH 30 5.
- Page 3 Service guide Disassembling and assembling VRH 5 - 120 (F) Disassembling 1. Loosen counter nut and screw adjustment 2. Loosen and unscrew end cover screw fully out. 3. Remove end cover. 4. Remove spring. 5. Remove tube. 6. Remove puppet ©...
- Page 4 Service guide Disassembling and assembling VRH 5 - 120 (F) 7. Loosen valve seat. 8. Unscrew valve seat. 9. Remove puppet. 11. Insert special tool. 12. Loosen poppet guide. 4 | AX384036216157en-000103 © Danfoss | 2024.01...
- Page 5 Service guide Disassembling and assembling VRH 5 - 120 (F) 13 Unscrew poppet guide. Assembling 2. Tighten as speci ed in the drawing. 1. Insert poppet guide 4. Insert poppet. © Danfoss | 2024.01 AX384036216157en-000103 | 5...
- Page 6 Service guide Disassembling and assembling VRH 5 - 120 (F) 5. Insert tube. 6. Insert spring. 7. Mount the cover. 8. Tighten as speci ed on the drawing. 10. Insert valve seat. 9. Insert poppet. 6 | AX384036216157en-000103 © Danfoss | 2024.01...
- Page 7 Service guide Disassembling and assembling VRH 5 - 120 (F) 11. Tighten as speci ed on the drawing. © Danfoss | 2024.01 AX384036216157en-000103 | 7...
- Page 8 Service guide Disassembling and assembling VRH 5 - 120 (F) Service kit liste for VRH 5 VRH 5 kit Pos. Qty. Unit Designation O-ring 23,7 x 2,8 mm Cone guide O-ring (Ø15,0 x 1,5) Spring guide Spring Special tool HEX key 7 mm...
- Page 9 Service guide Disassembling and assembling VRH 5 - 120 (F) 3.1 Exploded view VRH 5 © Danfoss | 2024.01 AX384036216157en-000103 | 9...
- Page 10 Service guide Disassembling and assembling VRH 5 - 120 (F) Service kit liste for VRH 30 VRH 30 joint kit Pos. Qty. Unit Designation O-ring 23,7 x 2,8 mm Cone guide O-ring (Ø15,0 x 1,5) Spring guide Spring Special tool...
- Page 11 Service guide Disassembling and assembling VRH 5 - 120 (F) 4.1 Exploded view VRH 30 © Danfoss | 2024.01 AX384036216157en-000103 | 11...
- Page 12 Service guide Disassembling and assembling VRH 5 - 120 (F) Service kit liste for VRH 60 VRH 60 joint kit Pos. Qty. Unit Designation Valve seat Cone Cone guide Special tool HEX key 7mm VRH 60 10-40 bar (180G0001) Spring...
- Page 13 Service guide Disassembling and assembling VRH 5 - 120 (F) 5.1 Exploded view VRH 60 © Danfoss | 2024.01 AX384036216157en-000103 | 13...
- Page 14 Service guide Disassembling and assembling VRH 5 - 120 (F) Service kit list for VRH 120 VRH 120 joint kit Pos. Qty. Unit Designation Valve seat Cone Cone guide Special tool HEX key 7mm VRH 120 25-80 bar (180G0020) Spring...
- Page 15 Service guide Disassembling and assembling VRH 5 - 120 (F) 6.1 Exploded view VRH 120 © Danfoss | 2024.01 AX384036216157en-000103 | 15...
- Page 16 Service guide Disassembling and assembling VRH 5 - 120 (F) 6.2 Exploded view VRH 120F 16 | AX384036216157en-000103 © Danfoss | DCS-SGDPT/SI | 2024.01...
