VLT Ea4 Parallel Drive Modules
Operating Guide
9.
Connect the microswitch to the microswitch connector provided on the top of the drive module.
Example
Illustration 9: Positioning the Control Shelf for EMC-compliant Installation
1
Control shelf must stay below this point
2
Control shelf must stay above this point
Danfoss A/S © 2023.01
Mechanical Installation
AQ434333248451en-000101 / 130R1286 | 21
1
2
