CBFTF10xx-11x
Operation
-- Continued
Product Features -- Continued
Congestion Reduction
The CBFTF10xx-11x media converter does not forward collision signals or
error packets from one collision domain to another, improving baseline
network performance. In addition, the media converter filters packets
destined for local devices, also reducing network congestion.

Auto-Negotiation

The Auto-Negotiation feature allows the CBFTF10xx-11x media converter to
automatically configure itself to achieve the best possible mode of operation
over a link. The media converter broadcasts its speed (10 Mb/s or 100 Mb/s)
and duplex capabilities (full or half) to the other devices and negotiates the
best mode of operation. Auto-Negotiation allows quick and easy installation
because the optimal link is established automatically.
A scenario where the media converter is linked to a non-negotiating device is
a case where the user may want to disable Auto-Negotiation. In this instance,
the mode of operation will drop to the least common denominator between
the two devices (e.g.: 10 Mb/s, half-duplex). Disabling this feature gives the
user the ability to force the connection to the best mode of operation.
AutoCross™
When the AutoCross feature is activated, it allows either straight-through
(MDI) or crossover (MDI-X) copper cables to be used when connecting to
10Base-T or 100Base-TX devices. AutoCross determines the characteristics of
the connection and automatically configures the unit to link up, regardless if
the copper cable is MDI or MDI-X configuration.
recommends leaving the device in the default "enable" mode.)
10
24-Hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
(Transition networks

Cable Specifications

The physical characteristics must meet or exceed IEEE 802.3™ specifications.

Fiber Cable

Bit Error Rate:
single mode fiber (recommended):
Multimode fiber (recommended):
Multimode fiber (optional):
CBFTF1011-110
CBFTF1013-110
Fiber Optic Transmitter Power:
Fiber Optic Receiver Sensitivity:
Link Budget:
CBFTF1014-110
Fiber-optic Transmitter Power:
Fiber-optic Receiver Sensitivity:
Link Budget:
CBFTF1015-110
(long haul)
Fiber-optic Transmitter Power:
Fiber-optic Receiver Sensitivity:
Link Budget:
CBFTF1016-110
(extra long haul)
Fiber-optic Transmitter Power:
Fiber-optic Receiver Sensitivity:
Link Budget:
CBFTF1017-110 (long wave length)
Fiber-optic Transmitter Power:
Fiber-optic Receiver Sensitivity:
Link Budget:
CBFTF1018-110
Fiber-optic Transmitter Power:
Fiber-optic Receiver Sensitivity:
Link Budget:
CBFTF1025-110
Fiber-optic Transmitter Power:
Fiber-optic Receiver Sensitivity:
Link Budget:
CBFTF1029-110
CBFTF1029-111
Fiber-optic Transmitter Power:
Fiber-optic Receiver Sensitivity:
Link Budget:
CBFTF1029-112
CBFTF1029-113
Fiber-optic Transmitter Power:
Fiber-optic Receiver Sensitivity:
Link Budget:
The fiber optic transmitters on this device meet Class I Laser safety requirements
per IEC-825/CDRH standards and comply with 21 CFR1040.10 and
21CFR1040.11.
techsupport@transition.com -- Click the "Transition Now" link for a live Web chat.
<10-9
9 µm
62.5/125 µm
100/140, 85/140, 50/125 µm
1300 nm multimode
1300 nm multimode
min: -19.0 dBm max: -14.0 dBm
min: -30.0 dBm max: -14.0 dBm
11.0 dB
1310 nm single mode
min: -15.0 dBm max: -8.0 dBm
min: -31.0 dBm max: -8.0 dBm
16.0 dB
1310 nm single mode
min: -8.0 dBm max: -2.0 dBm
min: -34.0 dBm max: -7.0 dBm
26.0 dB
1310 nm single mode
min: -5.0 dBm max: 0.0 dBm
min: -34.0 dBm max: -7.0 dBm
29.0 dB
1550 nm single mode
min: -5.0 dBm max: 0.0 dBm
min: -34.0 dBm max: -7.0 dBm
29.0 dB
1300 nm multimode
min: -19.0 dBm max: -14.0 dBm
min: -33.5 dBm max: -14.0 dBm
14.5 dB
1310 nm single mode
min: -11.0 dBm max: -3.0 dBm
min: -20.0 dBm max: -3.0 dBm
9.0 dB
1310 nm (TX) / 1550 nm (RX) simplex
1550 nm (TX) / 1310 nm (RX) simplex
min: -13.0 dBm max: -6.0 dBm
min: -32.0 dBm max: -3.0 dBm
19.0 dB
1310 nm (TX) / 1550 nm (RX) simplex
1550 nm (TX) / 1310 nm (RX) simplex
min: -8.0 dBm max: -3.0 dBm
min: -33.0 dBm max: -3.0 dBm
25.0 dB
11
