TROUBLESHOOTING SUGGESTIONS

NOTE: Refer to status LED description on last page.
If a Media Converter fails, ask the following questions:
1. Is the Power LED on the media converter illuminated?
NO
• Is the power adapter the proper voltage and cycle frequency
for the AC outlet? NOTE: Refer to the "Power Supply
Requirements" on the back page.
• Is the power adapter properly installed in the media converter
and in the outlet?
• Contact Technical Support: (800) 260-1312/(800) LAN-
WANS.
YES
• Proceed to step 2.
2. Is the UTP/STP LED illuminated?
NO
• Check twisted pair cables for proper connection.
• Check RJ-45 connector for correct twisted pair cable
configuration.
• Contact Technical Support: (800) 260-1312/(800) LAN-
WANS.
YES
• Proceed to step 3.
3. Is the Fiber LED illuminated?
NO
• Check fiber cables for proper connection.
• Verify that TX and RX cables on media converter are
connected to RX and TX ports, respectively, on other device.
• Contact Technical Support: (800) 260-1312/(800) LAN-
WANS.
YES
• Contact Technical Support: (800) 260-1312/(800) LAN-
WANS.
6
• Install one end of cable to female BNC connector on host.
• Install other end of cable to female BNC connector on media
converter.
3. Connect B-CF-01 media converter near host to B-CF-01 media
converter near terminal device.
• Locate or build fiber cable that conforms to cable
specifications (See page 7) with male fiber connectors at both
ends.
• Connect one end of first fiber cable to B-CF-01 media converter
TX connector.
• Connect other end of that fiber cable to second B-CF-01 media
converter RX connector.
• Connect one end of second fiber cable to B-CF-01 media
converter RX connector.
• Connect other end of that fiber cable to B-CF-01 media
converter TX connector.
4. Connect B-CF-01 media converter near terminal device to terminal
device.

Twisted-pair:

NOTE: Install TRANSITION Networks balun part number: B-4554
between RJ-45 cable and terminal device coax connector.
Install balun at terminal device coax connector.
•
• Connect male RJ-45 plug connector on one end of cable to
female RJ-45 connector marked "UTP/STP" on media converter.
• Connect male RJ-45 plug connector at other end of cable to
balun on terminal device.
Coaxial:
• Connect male coax connector on one end of cable to female
RJ-45 connector marked "Coax" on media converter.
• Connect male coax connector at other end of cable to female
coax connector on terminal device.
5. Connect B-CF-01 media converter(s) to power.
• Locate correct power supply adapter for site installation. (See
back page.)
• Connect media converter power connector at end of power
supply adapter cord to B-CF-01 media converter power
receptacle.
• Connect 2-prong or 3-prong external power connector on
other end of power supply adapter cord to external AC power.
C/B-CF-01
3
