Installation NOTES

All cable connections to the C/B-CF-01 MUST be
AT LEAST 7.6 meters (25 feet) in length.
To install the C/B-CF-01 series media converter:
1. Install the C/B-CF-01 in the E-MCC-1600 chassis.
NOTE: Media Converter Slide-in-Modules can be installed in any
installation slot, in any order.
• Remove Media Converter Slide-in-Module protective plate
from selected installation slot by removing two screws that
secure plate to front of E-MCC-1600. Retain one installation
screw.
• Carefully slide Media Converter Slide-in-Module into
installation slot, aligning Media Converter Slide-in-Module
with installation guides.
NOTE: Ensure that the Media Converter Slide-in-Module is firmly
seated against the backplane.
• Secure Slide-in-Module by installing retained installation
screw.
2. Connect host signal to C/B-CF-01 media converter.
NOTE: Set the configuration switch (located on the side of the media
converter) according to site requirements, using the following:
Switch 1 NOT USED
Switch 2 UP = Twisted Pair
DOWN = Coax
Twisted-pair:
• Locate or build twisted-pair cables (See specifications, page 7)
with male RJ-45 plug connectors at both cable ends.
NOTE: Install TRANSITION Networks balun part number: B-4554
between RJ-45 cable and coax connector.
• Install balun at host coax connector.
• Connect male RJ-45 plug connector at one end of twisted pair
cable to balun on host coax connector.
• Connect male RJ-45 plug connector at other end of cable to
female RJ-45 connector on B-CF-01 media converter.
Coax:
• Locate or build coaxial RG-62 cables (See specifications, page
7) with male BNC connectors at both ends.
2

CABLE SPECIFICATIONS

The physical characteristics of the cable must meet or exceed the following:
FIBER CABLE
MULTIMODE
Fiber Optic Cable Recommended:
Fiber Optic Transmitter Power:
Fiber Optic Receiver Sensitivity:
Wavelength:
Bit error rate:
Maximum Cable Distance:
SINGLEMODE
Fiber Optic Cable Recommended:
Fiber Optic Transmitter Power:
Fiber Optic Receiver Sensitivity:
Wavelength:
Bit error rate:
Maximum Cable Distance:
TWISTED PAIR CABLE AND CONNECTOR
Category 3 wire or better is required; category 5 wire is recommended. Either
shielded twisted pair (STP) or unshielded twisted pair (UTP) can be used. DO
NOT USE FLAT OR SILVER SATIN WIRE.
Category 3:
Gauge
Attenuation
Differential Characteristic Impedance
Category 5:
Gauge
Attenuation
Differential Characteristic Impedance
Minimum UTP/STP Cable Distance:
Maximum UTP/STP Cable Distance:
NOTE: The active pair in a twisted-pair
copper 3270-compliant network are pins
4 & 5. Use only dedicated wire pairs
(such as blue/white & white/blue,
orange/white & white/orange) for the
active pins.
RG-62 Cable
Cable Characteristics:
Cable type
:
Impedance:
Mutual Capacitance:
Maximum Cable Distance:
Minimum Distance/Connection
C/B-CF-01
62.5 / 125 µm multimode fiber
min: -19.0 max: -14.0
dBm dBm
min: -32.5 max: -14.0
dBm dBm
850nM
-9
10
2 kilometers
9 µm singlemode fiber
min: -27.0 max: -17.0
dBm dBm
min: -32.5 max: -13.0
dBm dBm
1300nM
-9
10
8 kilometers
24 to 22 AWG
28 dB/1000' @ 10 MHz
100 ±10% @ 10 MHz
24 to 22 AWG
20 dB/1000' @ 10 MHz
100 ±10% @ 10 MHz
1.8 meters (6 feet)
)
762 meters (2500 feet
Straight Through Cable
3 3
4 4
RJ-45 RJ-45
connector connector
5 5
6 6
Coaxial RG-62
93 @ 10 MHz
13 pF/ft ±20% @ 10 MHz
307 meters (1000 feet)
: 1.8 meters (6 feet)
