TVLogic F-7HS Operation Manual page 12

FHD Hight Bright Field Monitor
05 MENU OPERATIONS
[2] COLOR
COLOR같이
STANDARD
VIDEO RANGE
PEAK LUMINANCE
BLACK LEVEL
COLOR GAMUT
COLOR TEMP
EOTF
LOCAL DIMMING
EETF
HLG SG
S . G
CAM LUT
CAM LUT THROUG
• STANDARD
- Used to select the color and dynamic range of
the screen.
- Available options are HD, UHD, DCI-P3, PQ, HLG,
SLog3 and User1/2/3.
• VIDEO RANGE
- Used to select the range of digital video signal.
- [FULL]: ]: Input signal 1~254(8bit), 4~1019(10bit)
- [LIMITED109]: Input signal Y': 16~254, CbCr:
16~240(8bit) / Y': 64~1019, CbCr: 64~1019(10bit)
*Activates only in [STANDARD - USER 1/2/3] mode.
• PEAK LUMINANCE
- Used to select the Peak Luminance of the
monitor.
- Selectable levels are [100] ~ [1000] with 100
increment, [1000] ~ [10000] with 1000 increment.
*Activates only in [STANDARD - USER 1/2/3] mode.
12
F-7HS
HD
LIMITED109
100
0.001
BT709
6500K
2.4
OFF
OFF
OFF
OFF
OFF
PAGE (1/2)
• BLACK LEVEL
- The minimum black level of the video signal
can be set differently depending on the
performance of the monitor or the lighting
environment.
- Available modes are from [0.000] to [0.010]
with 0.001 increment, from [0.010] to [0.100]
with 0.010 increment, from [0.100] to [0.900]
with 0.100 increment.
* Activates only in the User1/2/3 mode.
• COLOR GAMUT
- Used to select the standard color gamut.
- Available options are BT709, DCI, BT2020, NATIVE.
*Activates only in [STANDARD - USER 1/2/3] mode.
• COLOR TEMP (Color Temperature)
- Controls the color temperature.
- Available options are 6500K, 9300K, USER 1/2/3.
*Activates only in [STANDARD - USER 1/2/3] mode.
• EOTF (Electro-Optical Transfer Function)
- Electrophotic conversion Functions(ex: Gamma
or HDR curve).
- Available modes are 2.2, 2.4, 2.6, PQ, HLG and
SLOG3.
*Activates only in [STANDARD - USER 1/2/3] mode.
• LOCAL DIMMING (* Not Supported)
- Used to set the Local Dimming Backlight mode.
- This mode is supported by the local dimming
backlight model and does not support F-7HS.
