RS485 Installation and Set-...
Coil 0
33 Control not ready
34 Frequency converter not
ready
35 Coasting stop
36 No alarm
37 Not used
38 Not used
39 Not used
40 No warning
41 Not at reference
42 Hand mode
43 Out of freq. range
44 Stopped
45 Not used
46 No voltage warning
47 Not in current limit
48 No thermal warning
Table 8.3 Frequency Converter status word (FC profile)
8 8
Bus adress Bus register
0 1
1 2
2 3
3 4
4 5
5 6
6 7
7 8
8 9
9 10
19 20
29 30
1
Value written in Modbus RTU telegram must be one or less than register number. E.g. Read Modbus Register 1 by writing value 0 in telegram.
* Used to specify the index number to be used when accessing an indexed parameter.
78
VLT Micro Drive Design Guide
1
Control ready
Frequency converter ready
Safety closed
Alarm
Not used
Not used
Not used
Warning
At reference
Auto mode
In frequency range
Running
Not used
Voltage warning
Current limit
Thermal warning
PLC Register Content
1
40001 Reserved
40002 Reserved
40003 Reserved
40004 Free
40005 Free
40006 Modbus conf
40007 Last error code
40008 Last error register Read only
40009 Index pointer
40010 FC par. 0-01
40020 FC par. 0-02
40030 FC par. xx-xx
MG02K102 - VLT
Access Description
Reserved for Legacy Drives VLT 5000 and VLT 2800
Reserved for Legacy Drives VLT 5000 and VLT 2800
Reserved for Legacy Drives VLT 5000 and VLT 2800
Read/Write TCP only. Reserved for Modbus TCP (p12-28 and 12-29 -
store in Eeprom etc.)
Read only Error code recieved from parameter database, refer to
WHAT 38295for details
Address of register with which last error occurred, refer
to WHAT 38296 for details
Read/Write Sub index of parameter to be accessed. Refer to WHAT
38297 for details
Dependent on Parameter 0-01 (Modbus Register = 10 parameter
parameter access number
20 bytes space reserved pr parameter in Modbus Map
Dependent on Parameter 0-02
parameter access 20 bytes space reserved pr parameter in Modbus Map
Dependent on Parameter 0-03
parameter access 20 bytes space reserved pr parameter in Modbus Map
®
