1 Overview

The DAC63004WCSP-EVM
DAC63004W and DAC53004W commercial devices. The DAC63004WCSP-EVM has optional, nonpopulated
components that can be used to evaluate the DACx3004W with external FemtoFET
source applications in a small, 4-mm × 4-mm solution size.
The 12-bit DAC63004W and 10-bit DAC53004W are a pin-compatible family of ultra-low power, quad-channel,
buffered, voltage-output and current-output smart digital-to-analog converters (DACs). The DAC outputs are
capable of both voltage and current output. The DACx3004W support Hi-Z power-down mode and Hi-Z
output during power-off conditions. The DAC outputs provide a force-sense option for use as a programmable
comparator and current sink. The multifunction GPIO, function generation, and nonvolatile memory (NVM)
enable these smart DACs for use in applications and design reuse without the need for runtime software. These
devices also automatically detect I

1.1 Kit Contents

Table 1-1 details the contents of the EVM kit. Contact the nearest TI Product Information Center if any
component is missing. Make sure to verify the latest versions of the related software at the Texas Instruments
website, www.ti.com. Table 1-2
components are available for purchase from the Texas Instruments website at www.ti.com.
DAC63004WCSP-EVM evaluation board PCB
USB micro-B plug to USB-A plug cable
BOOSTXL-DAC-PORT
™
BoosterPack
TM4C1294 Connected LaunchPad
(In this document, the LaunchPad Evaluation Kit is referred to as TI
launchpad)

1.2 Related Documentation from Texas Instruments

The following document provides information regarding Texas Instruments integrated circuits used in the
assembly of the DAC63004WCSP-EVM. This user's guide is available from the TI web site under literature
number SLAU879. Any letter appended to the literature number corresponds to the document revision that is
current at the time of the writing of this document. Newer revisions may be available from the TI web site
at www.ti.com, or call the Texas Instruments Literature Response Center at (800) 477-8924 or the Product
Information Center at (972) 644-5580. When ordering, identify the document by both title and literature number.
SLAU879 – DECEMBER 2022
Submit Document Feedback
is an easy-to-use platform to evaluate the functionality and performance of the
2
C, SPI, and PMBus interfaces, and contain an internal reference.
lists the optional components not included with the kit. These optional

Table 1-1. Contents of DAC63004WCSP-EVM Kit

Item

Table 1-2. Optional Components Not Included With Kit

Item
digital-to-analog converter (DAC)
plug-in module
™ Evaluation Kit (EK-TM4C1294XL)

Table 1-3. Related Documentation

Document
DAC63004W product page
DAC53004W product page
Copyright © 2022 Texas Instruments Incorporated
™
MOSFETs for high current
Quantity
1
1
Quantity
1
1
Literature Number
SLASF72
DAC63004WCSP-EVM User's Guide
