Detailed Description
3.1.1.1 Signal Definitions
The DAC63004WCSP-EVM provides access to all DAC pins through connection J1 and J2.
Table 3-2 list the J1 and J2 pin definitions. J8 and J9 provide access to the current outputs when the optional
components are populated.
8 DAC63004WCSP-EVM User's Guide
Table 3-3 and Table 3-4 list the J8 and J9 pin definitions.

Table 3-1. DAC63004WCSP-EVM J1 Pin Definitions

Pin# Signal
1 GND Ground
2 DAC_SDI SPI SDI signal for DAC
3 DAC_SYNC SPI SYNC signal for DAC
4 DAC_SDA I
5 GND Ground
6 GND Ground
7 NC Not connected
8 FTDI_GPIO3 GPIO3 output of the onboard controller
9 DAC_GPIO GPIO Input for DACx3004W
10 DAC_VREF DAC_VREF
11 DAC_VREF VREF input to the DAC
12 DAC_CAP LDO bypass capacitor
13 DAC_FB0 Feedback pin for DAC VOUT0
14 DAC_OUT0 Output pin for DAC VOUT0
15 DAC_OUT1 Output pin for DAC VOUT1
16 DAC_FB1 Feedback pin for DAC VOUT1

Table 3-2. DAC63004WCSP-EVM J2 Pin Definitions

Pin# Signal
1 DAC_VDD VDD power supply for DAC
2 DAC_SCLK SPI SCLK
3 DAC_SDO SPI SDO
4 DAC_SCL I
5 EXT_REF External reference input for DAC
6 GND Ground
7 GND Ground
8 GND Ground
9 NC Not connected
10 NC Not connected
11 DAC_FB3 Feedback pin for DAC VOUT3
12 DAC_OUT3 Output pin for DAC VOUT3
13 GND Ground
14 GND Ground
15 DAC_OUT2 Output pin for DAC VOUT2
16 DAC_FB2 Feedback pin for DAC VOUT2

Table 3-3. DAC63004WCSP-EVM J8 Pin Definitions

Pin# Signal
1 IOUT0 Current output connection for Q1
2 IOUT1 Current output connection for Q2

Table 3-4. DAC63004WCSP-EVM J9 Pin Definitions

Pin# Signal
1 IOUT2 Current output connection for Q3
2 IOUT3 Current output connection for Q4
