Schematic, PCB Layout, and Bill of Materials
Designator Quantity
R29, R31 2
R30 1
R33, R44 2
R34 1
R39, R40, R41, R42 0
R43 1
SH-J1, SH-J2, SH-J3, SH-J4 4
U1 1
U2, U6 2
U3 1
U4 1
Y1 1
22 DAC63004WCSP-EVM User's Guide
Table 4-1. DAC63004WCSP-EVM Bill of Materials (continued)
Value Description
10 Ω RES, 10.0, 1%, 0.063 W, 0402
12 kΩ 12 kOhms ±1% 0.1W, 1/10W Chip Resistor
0402 (1005 Metric) Automotive AEC-Q200
Thick Film
0 Ω 0 Ohms Jumper 0.1W, 1/10W Chip Resistor
0603 (1608 Metric) Automotive AEC-Q200
Thick Film
330 Ω RES, 330, 1%, 0.1 W, AEC-Q200 Grade 0,
0402
10 Ω RES, 10.0, 1%, .5 W, AEC-Q200 Grade 0,
0805
1 MΩ RES, 1.00 M, 1%, 0.1 W, AEC-Q200 Grade
0, 0603
1x2 Shunt, 100mil, Gold plated, Black
DAC63004YBHR
Voltage Level Translator Bidirectional 1
Circuit 2 Channel 24Mbps SM8
USB2.0 to QuadSPI/I2C Bridge IC,
VQFN-32
4-Bit Fixed Direction Voltage-Level
Translator with Schmitt- Trigger Inputs, and
Tri-State Outputs, WQFN14
Crystal, 12 MHz, 18 pF, SMD
Copyright © 2022 Texas Instruments Incorporated
Package Reference Part Number
0402 RK73H1ETTP10R0F
0402 ERJ-2RKF1202X
0603 ERJ-3GEY0R00V
0402 ERJ-2RKF3300X
0805 ERJ-P6WF10R0V
0603 CRCW06031M00FKEA
Shunt SNT-100-BK-G
DSBGA16 DAC63004YBHR
SSOP8 TCA9406DCTR
VQFN-32 FT4222HQ-D-R
WQFN14 TXU0304BQA
ABM3 ABM3-12.000MHZ-B2-T
www.ti.com
Manufacturer
KOA Speer
Panasonic ECG
Panasonic
Panasonic
Panasonic
Vishay-Dale
Samtec
Texas Instruments
Texas Instruments
FTDI
Texas Instruments
Abracon Corporation
