DEMO MANUAL DC3018A

PARTS LIST

ITEM QTY REFERENCE
Required Circuit Components
1 2 C2, C3
2 1 C4
3 3 C5, C6, C8
4 1 C9
5 1 C11
6 1 L1
7 1 R9
8 1 R10
9 1 R12
10 1 U1
Additional Demo Board Circuit Components
1 2 C1, C18
2 2 C7, C15
3 0 C10, C12
4 4 C13, C14, C16, C17
5 2 C19, C20
6 1 C21
7 2 C22, C23
8 1 L2
9 1 Q1
10 1 R1
11 1 R2
12 0 R3, R5, R7
13 2 R4, R13
14 2 R6, R11
15 1 R8
16 1 R14
17 1 R15
Hardware: For Demo Board Only
1 10 E1-E3, E5, E12, E14-E17, E20
2 6 E4, E7, E10, E13, E18, E21
3 5 E6, E8, E9, E11, E19
4 1 JP1
5 4 MP1-MP4
6 1 XJP4
8
PART DESCRIPTION
CAP ., 22µF, X5R, 25V, 20%, 0805
CAP ., 6.8pF, C0G, 50V, ±0.25pF, 0402
CAP ., 47µF, X5R, 6.3V, 20%, 0805, AEC-Q200
CAP ., 0.033µF, X7R, 25V, 10%, 0402
CAP ., 470pF, C0G, 50V, 5%, 0402, AEC-Q200
IND., 0.1µH, PWR, SHIELDED, 20%, 25.8A, 1.8mΩ, 4.3x4.3mm,
XEL4030, AEC-Q200
RES., 140k, 1%, 1/16W, 0402, AEC-Q200
RES., 100k, 1%, 1/16W, 0402, AEC-Q200
RES., 15k, 1%, 1/16W, 0402
IC, LOW VOLTAGE SYN. STEP-DOWN REG, LQFN-18
CAP ., 470µF, TANT, POSCAP , 6.3V, 20%, 7343, 18mΩ, TPE
CAP ., 0.1µF, X5R, 25V, 10%, 0402
CAP ., OPTION, 0402
CAP ., 10µF, X5R, 10V, 20%, 0603
CAP ., 0.22µF, X7R, 16V, 10%, 0402, AEC-Q200
CAP ., 1µF, X5R, 10V, 20%, 0402
CAP ., 0.1µF, X7S, 16V, 10%, 0201
IND., 100Ω AT 100MHz, FERRITE BEAD, 25%, 8A, 6mΩ, 1812
XSTR., MOSFET, N-CH, 40V, 14A, DPAK (TO-252)
RES., 1M, 1%, 1/16W, 0402, AEC-Q200
RES., 249k, 1%, 1/16W, 0402, AEC-Q200
RES., OPTION, 0402
RES., 0Ω, 1/16W, 0402, AEC-Q200
RES., 100k, 5%, 1/16W, 0402, AEC-Q200
RES., 20Ω, 1%, 1/16W, 0402, AEC-Q200
RES., 0.05Ω, 1%, 10W, 2818, AEC-Q200, METAL, HP
RES., 10k, 5%, 1/16W, 0402, AEC-Q200
TEST POINT, TURRET, 0.064" MTG. HOLE, PCB 0.062" THK
TEST POINT, TURRET, 0.094" MTG. HOLE, PCB 0.062" THK
CONN., BANANA JACK, FEMALE, THT, NON-INSULATED,
SWAGE, 0.218"
CONN., HDR, MALE, 1x3, 2mm, VERT, ST, THT
STANDOFF , NYLON, SNAP-ON, 0.50"
CONN., SHUNT, FEMALE, 2 POS, 2mm
MANUFACTURER/PART NUMBER
AVX, 08053D226MAT2A
MURATA, GJM1555C1H6R8CB01D
MURATA, GRT21BR60J476ME13L
WURTH ELEKTRONIK, 885012205053
TDK, CGA2B2C0G1H471J050BA
COILCRAFT, XEL4030-101MEB
VISHAY, CRCW0402140KFKED
VISHAY, CRCW0402100KFKED
VISHAY, CRCW040215K0FKED
ANALOG DEVICES, LTC3311SEV#PBF
PANASONIC, 6TPE470MI
AVX, 04023D104KAT2A
AVX, 0603ZD106MAT2A
MURATA, GCM155R71C224KE02D
MURATA, GRM153R61A105ME95D
MURATA, GRM033C71C104KE14D
WURTH ELEKTRONIK, 74279226101
VISHAY, SUD50N04-8M8P-4GE3
VISHAY, CRCW04021M00FKED
VISHAY, CRCW0402249KFKED
VISHAY, CRCW04020000Z0ED
VISHAY, CRCW0402100KJNED
VISHAY, CRCW040220R0FKED
VISHAY, WSHP2818R0500FEA
VISHAY, CRCW040210K0JNED
MILL-MAX, 2308-2-00-80-00-00-07-0
MILL-MAX, 2501-2-00-80-00-00-07-0
KEYSTONE, 575-4
WURTH ELEKTRONIK, 62000311121
KEYSTONE, 8833
WURTH ELEKTRONIK, 60800213421
