Fuji Electric Micro Control X Instruction Manual

Instruction Manual
Micro Control X
Model : PXF5/9
Global Sales Section
Instrumentation & Sensors Planning Dept.
1, Fuji-machi, Hino-city, Tokyo 191-8502, Japan
http://www.fujielectric.com
Phone: +81-42-514-8930 Fax: +81-42-583-8275
http://www.fujielectric.com/products/instruments/
Thank you for purchasing the Fuji module type temperature controller.
instructions.
The contents of this manual are subject to change without notice.
This manual is complied with possible care for the purpose of accuracy, however,
Fuji Electric shall not be held liable for any damages, including indirect damage, caused by
typographical errors,
absence of information or use of information in this manual.
Before using the product, confirm that it
matches the type ordered.
(For model code, please refer to pages 22 - 23.)
included.
Temperature Controller 1 unit
Instruction Manual 1 copy
Panel mounting adapter 2 pc
Waterproof packing 1 pc
Option
Quantity
Terminal cover* 1 pc ZZPPXF1-B100
PC loader
1 cable ZZP*TQ501923C3
communication cable
Shunt resistor
1 pc
*For PXF9, two terminal covers are necessary for one unit.
Please Read First (Safety Information)
Please read this section thoroughly before using and observe the mentioned safety warnings fully.
Safety warnings are categorized as "Warning" or "Caution". Failure to follow the instructions may
result in a safety hazard.
Warning
Mishandling may cause injury to the user or property damage.
Caution
equipment may be impaired.
1. Warning
1-1. Limitations in Use
This product is a temperature controller which was developed, designed and manufactured on the
premise that it would be used for general machinery.
In particular, if this product is to be used for applications that require the utmost safety as described
below, please take into consideration of the safety of the entire system and the machine by adopting
such means as a fail-safe design, a redundancy design as well as the conducting of periodical
inspections.
Please do not use this product for applications which directly involve human lives.
INP-TN2PXF5/9d-E
CAUTION
Related Information
Refer to the following reference materials
for details about the items described in this
manual.
Micro Controller (Model: PXF)
Operation Manual
Micro Controller (Model: PXF)
Communication Functions
The latest manuals can also be downloaded at the
1-2. Installation and Wiring
Overvoltage category
Pollution degree
Recommended fuse
Usage environment
transformer which has a basic insulation or higher degree of insulation). The basic insulation
requires a clearance at least 1.5 mm and a creepage of at least 3.0 mm. If such insulation is not
1) Over Voltage Category
3) Required level of Insulating
Please observe the following instructions to meet the requirements of safety standard.
Failure to observe these instructions violates safety standards. (This product is not a safety equipment.)
................................................................................................................................................
(mains circuit) and this equipment.
basic insulation or higher degree of insulation). The basic insulation requires a clearance at least 1.5 mm
compliance may become invalid.
to prevent an electric shock.
confuse voltage input with current input, or vice versa.
or IV.
applied.
energized, attach the terminal cover (optional) to prevent an electric shock. Before removing a terminal
cover, turn off all the power.
................................................................................................................................................
the insulation class for equipment meets usage requirements.
Basic insulation (1500 V AC)
Power supply (100 to 240V AC) Internal circuit
Process value input
Control output 1 (relay contact)
or
Remote SV input
Motorized valve OPEN output
Valve position feedback
Control output 2 (relay contact)
or
Control output 1
Motorized valve CLOSE output
(SSR drive, current, voltage)
Control output 2 (SSR drive, current,
Alarm output 4 and 5 (relay contact)
voltage) or Transfer output
Alarm output 1
Digital input 1 to 5
(relay contact)
Alarm output
1 to 3
(relay contact)
Alarm output 2
Communication (RS-485)
(relay contact)
(1) (2)
(1): When the 9th code is "J" AL 1 and 2: independent common
(2): When the 9th code is other than "J" AL 1 to 3: shared common
and national standards.
might remain on-state, or off-state. For safety, use a protective circuit outside.
as the equipment to meet your application. Please note that the improper settings may result in
Control output 1: heating control
Control output 2 (optional): cooling control
: Read this instruction manual thoroughly before using the product, and usethe product safely.
1-3. Maintenance
errors or failures may be caused.
if the product is used properly.
- 1 -
-10 °C to 50 °C
90% RH or below (with no condensation)
II
2
Indoor use
II
2
300Vac rms or 300Vdc
Functional insulation (500 V AC)
Power supply (24V DC/24V AC)
Control output 1 (relay contact)
or
Motorized valve OPEN output
CT input
Control output 2 (relay contact)
(PFB) input
or
Motorized valve CLOSE output
Alarm output 4 and 5 (relay contact)
Alarm output 1
(relay contact)
Alarm output
1 to 3
(relay contact)
Alarm output 2
(relay contact)
(1) (2)
by IEC 61010-1
No insulation
Internal circuit
Process value input
Remote SV input
CT input
Valve position feedback
(PFB) input
Control output 1
(SSR drive, current, voltage)
Control output 2 (SSR drive, current,
voltage) or Transfer output
Digital input 1 to 5
Communication (RS-485)
