- Page 1 RYS-L Type User's Manual MHT259a (Engl.)
- Page 2 CONTENTS 9.4 SX bus (SX bus direct connection) ････････････････ 9-8 SAFETY INSTRUCTION 9.5 T-link (T-link direct connection) ･･･････････････････ 9-11 1. GENERAL ････････････････････････････････ ････ 1-1 ････････････････････････････････････ ････････････････････････････････ ････････････････････････････････ ････ ････ 9.6 General-purpose communication (RS485 interface) ･･ 9-14 1.1 Outline ･･･････････････････････････････････････ 1-1 1.2 System configuration ･･･････････････････････････...
- Page 3 SAFETY INSTRUCTIONS In all stages of the basic planning of this equipment, its transport, installation, operation, maintenance and check, reference must be made to this manual and other related documents. The correct understanding of the equipment, information about safety and other related instructions are essential for this system.
- Page 4 DANGER ● ● ● ● Prior to inspection, turn off power and wait for at least five minutes. Otherwise, there is a risk of electric shock. ● ● ● ● Do not touch the amplifier when the commercial power is supplied. Otherwise, there is a risk of electric shock. CAUTION ●...
- Page 5 1. GENERAL 1.1 Outline The FALDIC-α series which corresponds to a host interface is an AC servo system for motion-control necessary for a driven machine. (1) Model type in this manual (a) Amplifier (*) : RYS□□□S3-LPS□, LSS□, LTS□ and LRS□ (b) Motor (*) : GYC□□□DC1-S＊−＊＊＊＊...
- Page 6 (c) Closely mountable amplifiers (i) Several amplifiers can be mounted sidewise spaced by less than 5 [mm] between themselves. In that case, however, the operation duty is not continuous but 80%ED. Refer to 3.2 (2) . (ii) Control power supply input terminals are provided. Maintenance is F A L D I C F A L D I C F A L D I C...
- Page 7 1.2 System configuration The following illustrates related devices of FALDIC-α system. Programmable operation display (POD) UG20 SYSTEM Ｆ１ Ｆ１ Ｆ１ Ｆ１ Ｆ２ Ｆ２ Ｆ２ Ｆ２ Ｆ３ Ｆ３ Ｆ３ Ｆ３ Ｆ４ Ｆ４ Ｆ４ Ｆ４ Ｆ５ Ｆ５ Ｆ５ Ｆ５ Programmable logic controller (PLC) Ｆ６...
- Page 8 Amplifier F A L D I C F A L D I C F A L D I C F A L D I C RYS401S3-LPS RYS401S3-LPS RYS401S3-LPS RYS401S3-LPS MODE MODE MODE MODE SHIFT SHIFT SHIFT SHIFT CHARGE CHARGE CHARGE CHARGE K80791543 K80791543...
- Page 9 1.3 Functions The FALDIC-α series has 3 types of control function for particular applications. (1) RYS-V type : Pulse train/speed control (velocity) Maximum input frequency 500 [kHz] Rotates according to pulse train from host control equipment, or speed command from encoder or variable resistor. The host interface has : ・DI/DO speed (minimum DI/DO), ・SX bus type,...
- Page 10 1.4 Explanation of model type Model type of amplifier and motor is expressed with a combination of figures and letters : (a) Amplifier R Y S 2 0 1 S 3 - L P S 6 Input voltage Amplifier, RYS : basic Phase Single Volt.
