6.7 Spare parts list of lathe bed

Index NO Parts NO.
201 BD11LB-201
202 BD11LB-202
203 BD11LB-203
204 BD11LB-204
205 BD11LB-205
206 BD11LB-206
207 BD11LB-207
208 BD11LB-208
209 BD11LB-209
210 BD11LB-210
211 BD11LB-211
212 BD11LB-212
213 BD11LB-213
214 BD11LB-214
215 BD11LB-215
216 BD11LB-216
217 BD11LB-217
218 BD11LB-218
219 BD11LB-219
220 BD11LB-220
221 BD11LB-221
222 BD11LB-222
223 BD11LB-223
224 BD11LB-224
225 BD11LB-225
226 BD11LB-226
227 BD11LB-227
228 BD11LB-228
229 BD11LB-229
230 BD11LB-230
231 BD11LB-231
232 BD11LB-232
233 BD11LB-233
234 BD11LB-234
235 BD11LB-235
236 BD11LB-236
237 BD11LB-237
238 BD11LB-238
239 BD11LB-239
240 BD11LB-240
241 BD11LB-241
242 BD11LB-242
243 BD11LB-243
244 BD11LB-244
245 BD11LB-245
246 BD11LB-246
247 BD11LB-247
248 BD11LB-248
249 BD11LB-249
250 BD11LB-250
251 BD11LB-251
252 BD11LB-252
253 BD11LB-253
254 BD11LB-254
Description
Bush
Tailstock spindle
Key DIN 6885 - A 3 x 3 x 10
Clamping handle
Handle seat
Clamping lever
Threaded pin - M5 x 12
Lubricating nipple
Washer
Clamping piece spindle sleeve
Clamping piece spindle sleeve
Threaded pin - M5 x 12
Lubricating nipple
Piece of centering of spindle sleeve
Tailstock marking
Handlewheel
Nut
Spiral spring
Scales ring
Handle
Socket head screw DIN 912-M5X16
Washer DIN 6340-12
Tailstock
Tailstock base
Set Screw M8X45
Clamping plate
Hex cap bolt
Adjustment device
Threaded pin ISO 4028 - M6 x 16
Brass clamping piece
Socket head screw ISO 4028 - M6 x 10
Washer DIN 6340-8
Lock washer DIN 6340-10
Hex head cap screw DIN 912-M10X35
Machine bed
Rack
Hex head cap screwDIN 912-M6X16
Lead screw
Hex head cap screw DIN 912-M8X20
Lubricating nipple
Bearing 51102
Bracket
Round nut M12X1.25
Shaft sleeve
Spiral spring
Shaft sleeve
Eccentric sha
Locking handle
Motor
Set Screw
Washer
Nut
Spring pin ISO 8752 - A4 x 24
Handle
Size Qty
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
2
1
1
1
2
1
1
1
1
3
3
4
4
1
1
6
1
2
1
2
1
2
1
1
1
1
1
230V 1
4
4
4
1
1
