Spare Parts List Of Cross Slide - Jet BD-11G Operating Manual

6.5.1 Spare parts list of cross slide

Index NO Parts NO.
21 BD11CS-21
25 BD11CS-25
26 BD11CS-26
27 BD11CS-27
28 BD11CS-28
29 BD11CS-29
30 BD11CS-30
31 BD11CS-31
32 BD11CS-32
33 BD11CS-33
34 BD11CS-34
35 BD11CS-35
40 BD11CS-40
41 BD11CS-41
42 BD11CS-42
43 BD11CS-43
44 BD11CS-44
45 BD11CS-45
46 BD11CS-46
47 BD11CS-47
48 BD11CS-48
49 BD11CS-49
50 BD11CS-50
51 BD11CS-51
52 BD11CS-52
60 BD11CS-60
61 BD11CS-61
62 BD11CS-62
63 BD11CS-63
64 BD11CS-64
65 BD11CS-65
66 BD11CS-66
Description
Slide bearing
Lever
Handle
Clamping bolt
Spring
Steel ball
Back clamp
Before clamp
Hex socket head screw DIN 912
Hex socket head screw DIN 912
Brake clamp
Hex socket head screw DIN 912
Oil nipple
Thread pin DIN 914
Hex socket head screw DIN 912
Cross slide
Brush pin
Hex socket head screw DIN 912
Nut
Hex socket head screw DIN 912
Gib cross slide
Spindle nut
Spindle
Spring pin DIN 1481
Dovetail guideway
Thread pin DIN 913
Brush pin
Bearing pedestal spindle
Washer DIN 6340
Hex socket head screw DIN 912
Scale collar
Guide pulley
Size Qty
2
1
1
1
1
1
1
1
M8X30 2
M8X40 1
1
M8X30 3
6mm 6
M6×10 1
M8×10 1
1
3
M6×30 1
M6 1
M6×30 1
1
1
1
4×16 1
1
M6×10 3
3
1
8 2
M8×20 1
1
1
