Spare Parts List Of Top Slide - Jet BD-11G Operating Manual

6.4.1Spare part list of top slide
Index NO Parts NO.
1 BD11TS-1
3 BD11TS-3
4 BD11TS-4
5 BD11TS-6
6 BD11TS-5
7 BD11TS-7
8 BD11TS-8
9 BD11TS-9
10 BD11TS-10
11 BD11TS-11
12 BD11TS-12
13 BD11TS-13
14 BD11TS-14
15 BD11TS-15
16 BD11TS-16
17 BD11TS-17
18 BD11TS-18
19 BD11TS-19
20 BD11TS-20
21 BD11TS-21
22 BD11TS-22
23 BD11TS-23
24 BD11TS-24
25 BD11TS-25
26 BD11TS-26
27 BD11TS-27
28 BD11TS-28
29 BD11TS-29
30 BD11TS-30
31 BD11TS-31
32 BD11TS-32
33 BD11TS-33
34 BD11TS-34
35 BD11TS-35
36 BD11TS-36
37 BD11TS-37
38 BD11TS-38
39 BD11TS-39
Description
Clamping handle
Clamping nut quadruple tool holder
Washer
Quadruple tool holder
Hex socket head screwDIN 912
Gib top slide
Top slide
Threaded bolt tool holder
Stop pin
Spring
Fixing pin
Hex socket head screwDIN 912
Nut
Spindle nut
Dovetail guideway top slide
Clamp collar
Scale collar
Hex socket head screwDIN 912
Spindle
Slide bearing
Bearing pedestal spindle
Scale collar handwheel
Scale guide
Lever
Handle
Clamping bolt
Spring
Steel ball
Pulley
Hex socket head screwDIN 912
Attachment handle
Hex socket head screw and washerDIN 912
Countersunk screw
Shaft
Chip Shield
Hex case
Hex socket head screw and nutDIN 912
Hex socket head screw and washerDIN 912
Size Qty
1
1
1
1
M8×35 8
1
1
1
1
1
1
M6×16 3
M6 3
1
1
1
1
M6×16 1
1
1
1
1
1
1
1
1
1
1
1
M6×25 1
1
M5×12 2
M5×6 2
1
1
1
M3×8 1
M3×6 2
