History Trending - Johnson Controls Frick QUANTUM LX Manual

ACCESSING:
DESCRIPTION: This is the

History Trending

Trending History Trending
, and finally
Real Time Trending Setup
screen. Each of the possible eight selectable channels will be shown at the bottom of the screen,
each in a different color. The color data values displayed in the chart correspond to the matching color of the trending
channels at the bottom of the screen.
History trending can save up to 2000 values for each
selected channel. History data is stored in Flash memory.
Flash memory is non-volatile and all information is
retained even if the power to the panel is lost. The
interval at which the data is saved can be adjusted.
FRICK ® QUANTUM™ LX COMPRESSOR CONTROL PANEL
OPERATION - SERVICE
-Trending - History Trending
SYSTEM STATUS
System Status...
screen. It is accessible from the
. This screen will display in a graphical chart format, the data values as selected on the
Trending...
History Trending
Main Menu by pressing
The events that can be logged are set using the Trending
Setup screen.
090-022 O (NOV 09)
Page 21
System Status... , then
