2. On the SIP page, enter values for the parameters indicated in
Note
Web Page Item
SIP Settings
Enable SIP Operation
Register with a SIP Server
Buffer SIP Calls
Play Stored Message
Auto-Answer Incoming Calls
Beep on Page
Primary SIP Server
Primary SIP User ID
Primary SIP Auth ID
Primary SIP Auth Password
Re-registration Interval (in seconds)
Backup SIP Server 1
Backup SIP User ID
Backup SIP Auth ID
Backup SIP Auth Password
Re-registration Interval (in seconds)
Operations Guide
The question mark icon (
after the Toggle Help button is pressed
Table 2-9. SIP Page Parameters
Description
When enabled, the device will transmit, receive, and process SIP messages
according to the configured SIP settings below.
When enabled, the device will attempt to register to the configured SIP Server(s) on
this page.
Device will buffer audio and play it back after hang up. Length of the buffer varies with
codec.
When selected, the caller will be prompted to select one of nine stored messages to
play through the speaker. Stored messages may be customized on the Audiofiles
page.
When selected, the device will automatically answer incoming calls. When Auto-
Answer Incoming Calls is disabled, the device will play a ring tone (corresponds to
Ring Tone on the Audiofiles page) out of the speaker until someone presses the Call
button to answer the call or the caller disconnects before the call can be answered.
Device will play the user defined "pagetone" audio file before playing a SIP page.
Enter the SIP server address as an IPv4 address in dotted decimal notation or a fully
qualified domain name. This parameter also becomes the host portion of the SIP-URI
for the device's extension on the primary SIP server. This field can accept entries of
up to 255 characters in length.
Specify the SIP User ID for the Primary SIP Server. This parameter becomes the user
portion of the SIP-URI for the device's extension on the primary SIP server. Enter up
to 64 alphanumeric characters.
Specify the Authenticate ID for the Primary SIP Server. This parameter is required for
SIP registration authentication. Enter up to 64 alphanumeric characters.
Specify the Authenticate Password for the Primary SIP Server. This parameter is
required for SIP registration authentication. Enter up to 64 alphanumeric characters.
The SIP Re-registration interval (in seconds) is the SIP Registration lease time, also
known as the expiry. The supported range is 30-3600 seconds. Enter up to 4 digits.
Enter the backup SIP server address as an IPv4 address in dotted decimal notation or
a fully qualified domain name. This parameter also becomes the host portion of the
SIP-URI for the device's extension on the backup SIP server. This field can accept
entries of up to 255 characters in length.
Specify the SIP User ID for the first backup SIP Server. This parameter becomes the
user portion of the SIP-URI for the device's extension on the first backup SIP server.
Enter up to 64 alphanumeric characters.
Specify the Authenticate ID for the first backup SIP server. This parameter is required
for SIP registration authentication. Enter up to 64 alphanumeric characters.
Specify the Authenticate Password for the first backup SIP server. This parameter is
required for SIP registration authentication. Enter up to 64 alphanumeric characters.
The SIP Re-registration interval (in seconds) is the SIP Registration lease time, also
known as the expiry. The supported range is 30-3600 seconds. Enter up to 4 digits.
932005A
) in the following table shows which web page items will be defined
.
Installing the SIP Speaker with Talk-Back
Device Configuration
Table 2-9.
