CyberData 011394 Series Operation Manual page 50

Web Page Item
Slow Blink
Fast Blink
Color
Brightness
Red
Green
Blue
MWI Strobe Settings
Blink Strobe on MWI
Scene
ADA Compliant
Slow Fade
Fast Fade
Slow Blink
Fast Blink
MWI Call Color
Brightness
Red
Green
Blue
Nightringer Settings
SIP Server
Operations Guide
Table 2-9. SIP Page Parameters (continued)
Description
Strobe will blink ON at the specified brightness for one second then OFF for one
second during the duration of the event.
Strobe will blink ON at the specified brightness then OFF five times per second during
the duration of the event.
Select desired color (only one may be chosen).
How bright the strobe will blink when there is a SIP Call. This is the maximum
brightness for "fade" type scenes.
The red LED value for SIP Call.
The green LED value for SIP Call.
The blue LED value for SIP Call.
Use this button to preview the strobe flashing behavior for the SIP Call Strobe
Settings.
The following strobe settings will only appear if you are using the Strobe Kit. If
you are not using the Strobe Kit, you will not see the strobe settings.
When selected, the strobe will blink a scene when a voicemail is waiting for its
extension.
Select desired scene (only one may be chosen).
Strobe will blink ON at the specified brightness for 150ms then OFF for 350ms during
the duration of the event.
Strobe will increase in brightness from 0 to the specified brightness and back to 0
over the course of about 3.5 seconds during the duration of the event.
Strobe will increase in brightness from 0 to the specified brightness and back to 0
over the course of about 1.5 seconds during the duration of the event.
Strobe will blink ON at the specified brightness for one second then OFF for one
second during the duration of the event.
Strobe will blink ON at the specified brightness then OFF five times per second during
the duration of the event.
Select desired color (only one may be chosen).
How bright the strobe will blink when there is a message waiting. This is the maximum
brightness for "fade" type scenes.
The red LED value for MWI.
The green LED value for MWI.
The blue LED value for MWI.
Use this button to preview the strobe flashing behavior for the MWI Strobe Settings.
Enter the SIP server address as an IPv4 address in dotted decimal notation or a fully
qualified domain name. This parameter also becomes the host portion of the SIP-URI
for the device's Nightringer extension on the SIP server. This field can accept entries
of up to 255 characters in length.
932005A
Installing the SIP Speaker with Talk-Back
Device Configuration
CyberData Corporation
43
