2.2.1.2 SIP Speaker with Talk-Back (with PoE Injector) to a 802.3af Compliant PoE Switch
In Figure
separately). A PoE Injector is a power supply solution for those who have a standard Non PoE
Switch.
Operations Guide
2-2, if a PoE switch is not available, you will need a PoE Injector, part #010867A (ordered
Figure 2-2. SIP Speaker with Talk-Back (with PoE Injector) to a Non PoE Switch
Non PoE Switch
SIP Speaker with Talk-Back
PoE Injector
(part #011124)
932005A
Installing the SIP Speaker with Talk-Back
Device Configuration
Non PoE Switch
Cat 5 Ethernet cable
