AD73360L
CONTROL REGISTER H

REGISTER BIT DESCRIPTIONS

Control Register A
CRA:0 Data/Program Mode. This bit controls the operating mode of the AD73360L. If CRA:1 is 0, a 0 in this bit places the
part in Program Mode. If CRA:1 is 0, a 1 in this bit places the part in Data Mode.
CRA:1 Mixed Mode. If this bit is a 0, the operating mode is determined by CRA:0. If this bit is a 1, the part operates in
Mixed Mode.
CRA:2 Reserved. This bit is reserved and should be programmed to 0 to ensure correct operation.
CRA:3 SPORT Loop Back. This is a diagnostic mode. This bit should be set to 0 to ensure correct operation.
CRA:4–6 Device Count Bits. These bits tell the AD73360L how many devices are used in a cascade. Both devices in the
cascade should be programmed to the same value ensure correct operation. See Table XVI.
CRA:7 Reset. Writing a 1 to this bit will initiate a software reset of the AD73360L.
Control Register B
CRB:0–1 Decimation Rate. These bits are used to set the decimation of the AD73360L. See Table XV.
CRB:2–3 Serial Clock Divider. These bits are used to set the serial clock frequency. See Table XIV.
CRB:4–6 Master Clock Divider. These bits are used to set the Master Clock Divider ratio. See Table XIII.
CRB:7 Control Echo Enable. Setting this bit to a 1 will cause the AD73360L to write out any control words it receives.
This is used as a diagnostic mode. This bit should be set to 0 for correct operation in Mixed Mode or Data Mode.
Control Register C
CRC:0 Global Power-Up. Writing a 1 to this bit will cause all six channels of the AD73360L to power up, regardless of
the status of the Power Control Bits in CRD-CRF. If fewer than six channels are required, this bit should be set to
0 and the Power Control Bits of the relevant channels should be set to 1.
CRC:1–4 Reserved. These bits are reserved and should be programmed to 0 to ensure correct operation.
CRC:5 Power-Up Reference. This bit controls the state of the on-chip reference. A 1 in this bit will power up the refer-
ence. A 0 in this bit will power down the reference. Note that the reference is automatically powered up if any
channel is enabled.
CRC:6 Reference Output. When this bit is set to 1, the REFOUT pin is enabled.
CRC:7 Reserved. This bit is reserved and should be programmed to 0 to ensure correct operation.
Control Register D
CRD:0–2 Input Gain Selection. These bits select the input gain for ADC1. See Table II.
CRD:3 Power Control for ADC1. A 1 in this bit powers up ADC1.
CRD:4–6 Input Gain Selection. These bits select the input gain for ADC2. See Table II.
CRD:7 Power Control for ADC2. A 1 in this bit powers up ADC2.
Control Register E
CRE:0–2 Input Gain Selection. These bits select the input gain for ADC3. See Table II.
CRE:3 Power Control for ADC3. A 1 in this bit powers up ADC3.
CRE:4–6 Input Gain Selection. These bits select the input gain for ADC4. See Table II.
CRE:7 Power Control for ADC4. A 1 in this bit powers up ADC4.
Table XII. Control Register H Description
7 6 5
INV TME CH6
Bit Name Description
0 CH1 Channel 1 Select
1 CH2 Channel 2 Select
2 CH3 Channel 3 Select
3 CH4 Channel 4 Select
4 CH5 Channel 5 Select
5 CH6 Channel 6 Select
6 TME Test Mode Enable
7 INV Enable Invert Channel Mode
4 3 2
CH5 CH4 CH3
–14–
1 0
CH2 CH1
REV. 0
