CONTROL REGISTER E
CONTROL REGISTER F
CONTROL REGISTER G
REV. 0
Table IX. Control Register E Description
7 6 5
PUI4 I4GS2 I4GS1
Bit Name Description
0 I3GS0 ADC3:Input Gain Select (Bit 0)
1 I3GS1 ADC3:Input Gain Select (Bit 1)
2 I3GS2 ADC3:Input Gain Select (Bit 2)
3 PUI3 Power Control (ADC3); 1 = ON, 0 = OFF
4 I4GS0 ADC4:Input Gain Select (Bit 0)
5 I4GS1 ADC4:Input Gain Select (Bit 1)
6 I4GS2 ADC4:Input Gain Select (Bit 2)
7 PUI4 Power Control (ADC4); 1 = ON, 0 = OFF
Table X. Control Register F Description
7 6 5
PUI6 I6GS2 I6GS1
Bit Name Description
0 I5GS0 ADC5:Input Gain Select (Bit 0)
1 I5GS1 ADC5:Input Gain Select (Bit 1)
2 I5GS2 ADC5:Input Gain Select (Bit 2)
3 PUI5 Power Control (ADC5); 1 = ON, 0 = OFF
4 I6GS0 ADC6:Input Gain Select (Bit 0)
5 I6GS1 ADC6:Input Gain Select (Bit 1)
6 I6GS2 ADC6:Input Gain Select (Bit 2)
7 PUI6 Power Control (ADC6); 1 = ON, 0 = OFF
Table XI. Control Register G Description
7 6 5
SEEN RMOD CH6
Bit Name Description
0 CH1 Channel 1 Select
1 CH2 Channel 2 Select
2 CH3 Channel 3 Select
3 CH4 Channel 4 Select
4 CH5 Channel 5 Select
5 CH6 Channel 6 Select
6 RMOD Reset Analog Modulator
7 SEEN Enable Single-Ended Input Mode
4 3 2
I4GS0 PUI3 I3GS2
4 3 2
I6GS0 PUI5 I5GS2
4 3 2
CH5 CH4 CH3
–13–
AD73360L
1 0
I3GS1 I3GS0
1 0
I5GS1 I5GS0
1 0
CH2 CH1
