TENSOR - BRIDGE DESK ASSEMBLY INSTRUCTIONS
2
Steps:
1.
Locate the first mending plate 1" from the edge of the bridge location as
shown. Install the mending plate to the table using (4) screws.
2.
Locate the second mending plate as far away from the first as the table
frame will allow. Install the mending plate to the table using (4) screws.
3.
Repeat Steps 1 and 2 on other table surface.
4.
Place tables upright and position to accept bridge in this position.
To report any issues with this product, please contact our customer service department at (888) 552-5699
M6x18
For more information, visit www.sitonit.net
54" and 60" Bridge Units
Add the external stiffener to the bridge unit as
near to the center of the table as the
placement of the mending brackets will allow.
In some cases, a mending bracket hole may
be covered by the table frame and the
attachment screw may be omitted.
No. C6258 Rev. B
