UG-900

ORDERING INFORMATION

BILL OF MATERIALS

Table 5. Bill of Materials for the
Qty. Reference Designator
4 C1, C4, C5, C7
2 C2, C6
4 C3, C8, C11, C12, C17, C20
2 C9, C10
2 C18, C19
10 J1 to J10
4 J21 to J24
2 P4, P7
8 R1, R4, R6, R8 to R12
4 R2, R3, R5, R7
2 TP1/VDD1, TP40/VDD2
4 TP2, TP3, TP41, TP42
2 TP5/VIN1, TP6/VIN2
1 U1
Table 6. Bill of Materials for the
Qty. Reference Designator
4 C1, C4, C5, C7
2 C2, C6
4 C3, C8, C11, C12, C17, C20
2 C9, C10
2 C18, C19
10 J1 to J10
4 J21 to J24
2 P4, P7
8 R2, R3, R5, R7, R9 to R12
4 R1, R4, R6, R8
2 TP1/VDD1, TP40/VDD2
4 TP2, TP3, TP41, TP42
2 TP5/VIN1, TP6/VIN2
1 U1

RELATED LINKS

Resource
ADN4651
ADN4652
EVAL-ADN4651EB1Z/EVAL-ADN4652EB1Z User Guide
EVAL-ADN4651EB1Z
Description
Capacitors, 100 nF, 0402
Capacitors, 1 µF, 0603
Capacitors, 0402
Capacitors, tantalum, 10 µF, Case C
Capacitors, 1 µF, 0402
Connectors, SMA, edge
Connectors, SMA, edge
2-pin, header and jumper
Resistors, 0402
Resistors, 100 Ω, 0402
Test points, yellow
Test points, black
Test points, red
ADN4651 5 kV rms, 600 Mbps, LVDS isolator
EVAL-ADN4652EB1Z
Description
Capacitors, 100 nF, 0402
Capacitors, 1 µF, 0603
Capacitors, 0402
Capacitors, tantalum, 10 µF, Case C
Capacitors, 1 µF, 0402
Connectors, SMA, edge
Connectors, SMA, edge
2-pin, header and jumper
Resistors, 0402
Resistors, 100 Ω, 0402
Test points, yellow
Test points, black
Test points, red
ADN4652 5 kV rms, 600 Mbps, LVDS isolator
Description
Product page, ADN4651, 5 kV rms, 600 Mbps, dual-channel isolated LVDS
Product page, ADN4652, 5 kV rms, 600 Mbps, dual-channel isolated LVDS
Rev. A | Page 12 of 13
Manufacturer Part Number
Multicomp MC0402X104K100CT
Multicomp MC0603X105K100CT
Not fitted Not applicable
AVX TAJC106K016RNJ
Multicomp MC0402X105K6R3CT
Johnson 142-0701-801
Not fitted Not applicable
TE Connectivity 826926-2 and 3M/969102-0000-DA)
Not fitted Not applicable
Multicomp MCMR04X1000FTL
Vero 20-313140
Vero 20-2137
Vero 20-313137
Analog Devices ADN4651BRWZ
Manufacturer Part Number
Multicomp MC0402X104K100CT
Multicomp MC0603X105K100CT
Not fitted Not applicable
AVX TAJC106K016RNJ
Multicomp MC0402X105K6R3CT
Johnson 142-0701-801
Not fitted Not applicable
TE Connectivity 826926-2 and 3M/969102-0000-DA)
Not fitted Not applicable
Multicomp MCMR04X1000FTL
Vero 20-313140
Vero 20-2137
Vero 20-313137
Analog Devices ADN4652BRWZ
