DEMO MANUAL
DC3054A-C

PARTS LIST

ITEM QTY REFERENCE
Required Circuit Components
1 2 C2, C3
2 2 C4, C5
3 1 C6
4 2 C13, C14
5 1 L1
6 1 R1
7 1 R2
8 1 U1
Additional Demo Board Circuit Components
1 1 C1
2 2 C7, C8
3 1 C9
4 2 C10, C11
5 0 C12
6 2 C18, C19
7 0 C15, C20
8 0 C16, C17
9 1 L2
10 1 Q1
11 1 R3
12 0 R4
13 1 R5
14 1 R6
15 1 R7
16 1 R8
17 1 R9
18 1 R10
19 1 R11
20 0 TP1, TP3
Hardware
1 10 E1-E3, E5, E12, E14-E16,
E19, E21
2 6 E4, E7, E11, E13, E18, E20 TEST POINT, TURRET, 0.094" MTG. HOLE, PCB 0.062" THK
3 5 E6, E8-E10, E17
4 1 JP1
5 1 JP2
6 4 MP1-MP4
7 0 TP2
8 2 XJP1, XJP2
8
PART DESCRIPTION
CAP ., 4.7μF, X6S, 6.3V, 20%, 0402
CAP ., 10μF, X7S, 6.3V, 20%, 0603
CAP ., 10pF, C0G, 50V, 5%, 0402
CAP ., 1μF, X7T, 6.3V, 20%, 0201
IND., 0.11μH, PWR, 20%, 8.8A, 0.01Ω, 0805
RES., 47.5k, 1%, 1/16W, 0402
RES., 18.2k, 1%, 1/16W, 0402, AEC-Q200
IC, 5V, 6A SYNCHRONOUS STEP-DOWN Silent Switcher,
2mm × 2mm LQFN
CAP ., 0.01μF, X5R, 10V, 10%, 0201
CAP ., 330μF, TANT, POSCAP , 6.3V, 20%, 7343, 25mΩ, TPE,
NO SUBS. ALLOWED
CAP ., 0.1μF, X7R, 10V, 10%, 0402, AEC-Q200
CAP ., 10μF, X7S, 6.3V, 20%, 0603
CAP ., OPTION, 0402
CAP ., 1000pF, X7R, 50V, 20%, 0402, 3-TERM, X2Y EMI FILTER
CAP ., 1000pF, X7R, 50V, 20%, 0402, 3-TERM, X2Y EMI FILTER
CAP ., OPTION, 0201
IND., 100Ω AT 100MHz, FERRITE BEAD, 25%, 8A, 6mΩ, 1812 WURTH ELEKTRONIK, 74279226101
XSTR., MOSFET, N-CH, 40V, 15.9A, PPAK SO-8
RES., 20Ω, 1%, 1/16W, 0402, AEC-Q200
RES., OPTION, 0402
RES., 10k, 5%, 1/16W, 0402, AEC-Q200
RES., 1MΩ, 1%, 1/16W, 0402, AEC-Q200
RES., 249k, 1%, 1/16W, 0402, AEC-Q200
RES., 100k, 5%, 1/16W, 0402
RES., 0Ω, 1/16W, 0402
RES., 10k, 5%, 1/10W, 0402, AEC-Q200
RES., 0.1Ω, 1%, 2W, 2512, SENSE, AEC-Q200
CONN., U.FL, RECEPT, ST SMD, 0Hz TO 6GHz 50Ω
TEST POINT, TURRET, 0.064" MTG. HOLE, PCB 0.062" THK
CONN., BANANA JACK, FEMALE, THT, NON-INSULATED,
SWAGE, 0.218"
CONN., HDR, MALE, 1×4, 2mm, VERT, ST, THT
CONN., HDR, MALE, 1×3, 2mm, VERT, ST, THT
STANDOFF , NYLON, SNAP-ON, 0.50"
CONN., TEST JACK, PLUG, 1POS, THT, VERT
CONN., SHUNT, FEMALE, 2POS, 2mm
MANUFACTURER/PART NUMBER
MURATA, GRM155C80J475MEAAD
TDK, C1608X7S0J106M080AC
MURATA, GJM1555C1H100JB01D
MURATA, GRM033D70J105ME01D
TDK, TFM201208BLD-R11MTCA
VISHAY, CRCW040247K5FKED
VISHAY, CRCW040218K2FKED
ANALOG DEVICES, LTC3309BEV#PBF
MURATA, GRM033R61A103KA01D
PANASONIC, 6TPE330ML
MURATA, GCM155R71A104KA55D
TDK, C1608X7S0J106M080AC
JOHANSON DIELECTRICS, 500X07W102MV4T
JOHANSON DIELECTRICS, 500X07W102MV4T
VISHAY, SIR426DP-T1-GE3
VISHAY, CRCW040220R0FKED
VISHAY, CRCW040210K0JNED
VISHAY, CRCW04021M00FKED
NIC, NRC04F2493TRF
YAGEO, RC0402JR-07100KL
VISHAY, CRCW04020000Z0ED
PANASONIC, ERJ2GEJ103X
IRC, LRC-LR2512LF-01-R100-F
HIROSE ELECTRIC, U.FL-R-SMT-1(10)
MILL-MAX, 2308-2-00-80-00-00-07-0
MILL-MAX, 2501-2-00-80-00-00-07-0
KEYSTONE, 575-4
WURTH ELEKTRONIK, 62000411121
WURTH ELEKTRONIK, 62000311121
WURTH ELEKTRONIK, 702935000
TELEDYNE, PK5-2.5MM-113
WURTH ELEKTRONIK, 60800213421
