Example: Writing parameter ID and integer value with 8 bits in TIA Portal
In the header, set the subindex to 1.
Set the write length to 7 bytes
WRREC_DB
REQ := 1 0
ID := 273
INDEX := 0x2530 Object Index
LEN := 15
8Byte + Data Length
RECORD :=
DONE =>
BUSY =>
Status/Result Output
ERROR =>
STATUS =>
Fig. 48 Write command of the PLC to the sensor for "Last peak" in peak selection
optoNCDT 1900 / Profinet
Enable-Flag
HW-ID
Write-Header (8 Byte)
0 0 0x01 0 0x07
PARAMID: 51029 VALUE: 2
0 0 0
0x3A 0xC7 0x00 0x02 0x00 0x00 0x00
