Assembly
5.4.2

RJ45 Connection

Source
Cable/power supply
Interface, terminal
PC1900-IE-x/OE-RJ45
PLC
Switch / Hub
PS 2020
Laser On/Off
PC / Ethernet
Fig. 17 ILD1900-Ix-E connection example, supply via optional power supply unit, laser on/off via hardware
optoNCDT 1900 / Profinet
Page 30
