8.6.3.5

Zeroing, Mastering

Name Parameter ID
Master enable 53001
Master set 53003
Master Value 53004
Setting masters/Zeroing – Step-by-Step:
True for Master enable (53001) specifies that the function is applied to the DIST1 signal.
Pass the value for zeroing/mastering to parameter 53004.
Start zeroing or mastering with True for Master set (53003).
optoNCDT 1900 / Profinet
Data type Description
Determine signal DIST1 for zeroing/mastering
BOOL 0 - False
1 - True
Perform zeroing or mastering or terminate
BOOL 0 - False
1 - True
Specify the thickness (or other parameter) of a master
FLOAT object.
Value range -2 to +2 x measuring range
Access
rw
rw
rw
