MICRO-EPSILON optoNCDT 1900 PROFINET Operating Instructions Manual page 57

Setting Sensor Parameters
Timestamp 32 Bit
Unlinearized 18 Bit
center of gravity
Measurement 18 Bit
frequency
State information transferred in the distance value
Distance value Description
262076 There is no peak present
262077 Peak is before measuring range (MR)
262078 Peak is after measuring range (MR)
262080 Measurement value cannot be evaluated
262081 Peak is too wide
262082 Laser is off
i
The sensor sends the cyclic process data in little-endian format. The acyclic requirements data is also in little-endian format;
records are read as little-endian and must also be written as little-endian. If the PLC uses the big-endian format, the byte order
must be swapped.
optoNCDT 1900 / Profinet
x Digital value
t Time stamp in µs
x Digital value
CG Center of gravity in %
x Digital value
f Frequency in Hz
[0; 4294967295]
[0; 1h11m34.967s]
[0; 262143]
[0; 100]
[2500; 100000]
1
t = x
1000
100
US = x
262143
x
f =
10
