Functional Principle, Technical Data
Model
ILD1900-
Signal input
Digital interface
Connection
Storage
Temperature
range
Operation
Shock (DIN EN 60068-2-27)
Vibration (DIN EN 60068-2-6)
Protection class (DIN EN
60529)
Material
Weight
Control and indicator ele-
ments
FSO = Full Scale Output
SMR = Start of measuring range, MMR = Mid of measuring range, EMR = End of measuring range
The specified data apply to a white, diffuse reflecting surface (Micro-Epsilon reference ceramic for ILD sensors)
1) Maximum measuring rate depending on fieldbus and bus cycle time; f actory setting: measuring rate 4 kHz, median 9;
2) Typical value with measurements at 4 kHz and median 9
3) In the mid of the measuring range; the specified value is only achieved by mounting on a metallic sensor holder. Good heat dissipation
from the sensor to the holder must be ensured.
4) Light spot diameter determined using a point-shaped laser with Gaussian fit (full 1/e² width); for ILD1900-2: determined with emulated
90/10 knife-edge method
5) Connection to PC via network cable
optoNCDT 1900 / Profinet
2-IE
6-IE
10-IE
integrated pigtail 0.3 m with 12-pin M12 plug;
optional extension to 3 m / 6 m / 9 m / 15 m (see accessories for suitable connection cable)
Select button: factory setting, change operation mode;
5
Web interface for setup
: Application-specific presets; peak selection, video signal; freely selectable
averaging possibilities; data reduction; setup management;
25-IE
50-IE
Laser on/off
PROFINET
-20 ... +70°C (non-condensing)
0 ... +50°C (non-condensing)
15 g / 6 ms
30 g / 20 ... 500 Hz
IP67
Aluminum housing
approx. 185 g (incl. pigtail)
3 color LEDs for power / status / PROFINET
100-IE
200-IE
500-IE
