Record Unsigned-Integer Parameter 0x2530, Example

Via this record, parameters of type UINT8, UINT16 and UINT32 can be read and written. First, use the header to write the parameter
ID to the record via subindex 1. Then you can write the UINT value to subindex 3 or read the complete record starting from subindex
0. You can also write subindex 1 to subindex 3 in a single write request to write parameter ID and UINT value in one go. The written
parameter ID remains stored in the record. Restarting the sensor resets the parameter ID to the default parameter ID.
Subindex Access
0 Read
1 Read/Write
2 Read/Write
3 Read/Write
4 Read
5 Read
6 Read
7 Read
Fig. 47 Unsigned integer parameter record 0x2530
optoNCDT 1900 / Profinet
Data type Name
UINT8 Subindex 0
UINT16 Parameter ID
UINT8 Reserved
UINT32 UINT32 value
STRING(14) Name of the parameter
STRING(8) Unit of the parameter
UINT32 Reserved
UINT32 Reserved
