DC-2/MC-1 Serial Communications Protocol
Application Header:
Command DC_RESP_FPD_CONTROL
Data Count 4
Application Data:
Data[0] FPD_CtrlReg0
Data[1] FPD_CtrlReg1
Data[2] FPD_CtrlReg2
Data[4] FPD_MinUpdate
7.3.14.3 Data Description
FPD_CtrlReg0: BitPack as defined in Appendix F FPD Control Registers
FPD_CtrlReg1: BitPack as defined in Appendix F FPD Control Registers
FPD_CtrlReg2: BitPack as defined in Appendix F FPD Control Registers
FPD_MinUpdate:
Data Type:
Default:
Range:
Conversion:

7.3.15 Set System Parameter Values

Command DC-2/MC-1 to replace the system parameter values with the values in this packet.
7.3.15.1 Command Packet Description
Application Header:
Command
Data Count
Application Data:
Data[0]
Data[1]
Data[...]
Data[SYS_PARAM_COUNT-1]
7.3.15.2 Data Description
sys_param_values:
Data Type:
Max
Array Size:
7.3.15.3 DC-2/MC-1 Response
The DC-2/MC-1 will assign the values from the packet to the system parameter values in Nonvolatile RAM,
and reset the unit to initialize the new values.
7.3.15.4 Data Validation
If any of the values exceeds it's maximum value the DC-2/MC-1 will ignore the command and transmit a
DC_NAK command with an error code DC_INVALID_DATA.

7.3.16 Set Effect Parameter Values

Commands DC-2/MC-1 to replace the given effect parameter values with the values in this packet.
0x88
0X04
nn
nn
nn
nn
This value sets the minimum time between FPD Notification Transmissions.
Unsigned 8 bit integer
50(100 mSec)
50 - 255 counts
500 counts/sec
DC_CMD_SET_SYS_PARAM_VALUES
SYS_PARAM_COUNT
sys_param_value[0]
sys_param_value[1]
sys_param_value[...]
sys_param_value[SYS_PARAM_COUNT-1]
Array of unsigned 8 bit Integers
Each value is set by its system parameter definition.
Set by the System Parameter Count in the "Unit Configuration Packet".
Printed on: 10/19/00
0x1E
nn
nn
nn
nn
nn
