DC-2/MC-1 Serial Communications Protocol

7.3.8 Get System Parameter Values

Request to DC-2/MC-1 for all current system parameter values. DC-2/MC-1 will respond with the "System
Parameter Values Packet".
7.3.8.1 Command Packet Description
Application Header:
Command DC_CMD_GET_SYS_PARAM_VALUES
Data Count 0
Application Data:
N/A
7.3.8.2 System Parameter Values Response Packet
Application Header:
Command
Data Count
Application Data:
Data[0]
Data[1]
Data[...]
Data[SYS_PARAM_COUNT-1] sys_param_value[SYS_PARAM_COUNT-1] nn
7.3.8.3 Data Description
sys_param_value:
Data Type:
Max:

7.3.9 Get Effect Definition by Id

Request to DC-2/MC-1 for an effect definition. DC-2/MC-1 will respond with "Effect Definition Packet".
7.3.9.1 Command Packet Description
Application Header:
Command DC_CMD_GET_EFFECT
Data Count 1
Application Data:
Data[0] EffectId
7.3.9.2 Data Description
EffectId:
Data Type:
Max:
7.3.9.3 Data Validation:
The EffectId must be a valid Effect Id. If it is not the DC-2/MC-1 will respond with a NAK packet and
error code DC_ERR_ INVALID_EFFECT_ID.
7.3.9.4 Effect Definition Response Packet
DC_RESP_SYS_PARAM_VALUES
SYS_PARAM_COUNT
sys_param_value[0]
sys_param_value[1]
sys_param_value[...]
Unsigned 8 bit integer Array.
Dependent on the parameter definition.
0x1B
0x01
nn
Unsigned 8 bit integer
Set by the Effect Count in the "Unit Configuration Packet".
Printed on: 10/19/00
0x1A
0x00
0x84
nn
nn
nn
nn
18 of 44
