Lexicon DC-1 V3 Owner's Manual

Lexicon DC-1 V3 Owner's Manual

Version 3 digital controller
Hide thumbs Also See for DC-1 V3:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Quick Reference Manual
Owner's Manual
DC-1 Digital Controller
Version 3
®
Dolby Digital
and
®
DTS
Versions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DC-1 V3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lexicon DC-1 V3

Summary of Contents for Lexicon DC-1 V3

  • Page 1 Owner's Manual DC-1 Digital Controller Version 3 ® Dolby Digital ® Versions...
  • Page 2 Lexicon, Inc. Copyright ©1999 Lexicon. Inc. All Rights Reserved. Lexicon Patent: U.S. no. 4, 862, 502; other patents pending on the DC-1. Lexicon, Inc.• 3 Oak Park • Bedford MA • 01730-1441 USA • Tel: 781-280-0300 • Fax: 781- 280-0490 CompuServe: GO LEXICON or 71154,1331@compuserve.com •...
  • Page 3 Dansk Suomi Vigtig information om sikkerhed Tärkeitä turvallisuusohjeita Säilytä nämä ohjeet tulevaa käyttöä varten. Gem denne vejledning til senere brug. Seuraa kaikkia yksikköön merkittyjä ohjeita ja varoituksia. Følg alle anvisninger og advarsler på apparatet. Käytä aina oikeaa verkkojännitettä. Tehovaatimukset selviävät valmistajan Apparatet skal altid tilsluttes den korrekte spænding.
  • Page 4 Deutsch Español Wichtige Sicherheitsanweisungen Instrucciones importantes de seguridad Heben Sie sich diese Sicherheitsanweisungen auch für später auf. Guarde esta instrucciones para uso posterior. Befolgen Sie alle auf der Vorrichtung stehenden Anweisungen und Warnungen. Utilice siempre el voltaje correcto. Diríjase a las instrucciones de operación Immer nur mit der richtigen Spannung verwenden! Die Gebrauchsanweisungen del fabricante para obtener las especificaciones de potencia.

  • Page 5: Table Of Contents

    DC-1 Version 3.0 Digital Controller Contents Introduction 1 Installation Controls and Indicators ............. 1 The Front Panel ............1 The Rear Panel ............2 The Remote Control ............ 3 Alternate Remote Control Functions Using the Shift and Record/Zone 2 buttons Connection ................
  • Page 6 Lexicon Using DC-1 Effects ............33 Customizing Effects • Comparing a modified effect to the factory preset version • Restoring the original parameter values of an Effect • Naming your custom Effect • Restoring the original Effect Name • Listening to only the DC-1 Effect •...
  • Page 7 The DC-1 also recreates 5.1 channel soundtracks with stunning accuracy, and takes them to a new level of realism with Lexicon’s proprietary Logic 7 technology. These effects allow you to expand 5.1 channel as well as two channel soundtracks for 7.1 and virtual 7.1 channel playback for an...
  • Page 8 Lexicon These enhancements ensure that film soundtracks, which are typically mixed for the acoustics of large theaters, sound as the filmmakers intended when played back in the relatively small environment of a home theater. Using the Because the DC-1 is designed to be customized for your system and your listening space, the information required for installation is extensive.
  • Page 9 Effect An effect is a configuration that determines how the DC-1 will process an input signal. The DC-1 can contain as many as 24 effects: Panorama, Nightclub, Concert Hall, Church, Cathedral, Party, 2-Channel, Music Surround, Music Logic, Logic 7, TV Matrix, Pro Logic, THX Cinema, Mono Logic, 5.1 2- Channel, 5.1 Music, 5.1 Logic 7, Dolby Digital, THX 5.1, DTS 2-Channel, DTS Music, DTS Logic 7, DTS Film and DTS THX 5.1.

  • Page 10: Installation

    Installation Installation DC-1 Version 3 Digital Controller Controls and Indicators The Front Panel 1. ON/OFF 3. REC/ZONE 2 6. MUTE 8. Display ON/OFF alternately puts the Press and hold to activate Attenuates the main audio A 2x20 backlit LCD displays DC-1 into and out of standby.
  • Page 11 Installation Lexicon The Rear Panel 1 = Ground CAUTION: Never make or break any connections to the DC-1 with the 2 = Ground rear-panel power ON. Make sure any associated amplifiers are turned 3 = Power On 4 = Unused off before turning this master power switch on or off.

  • Page 12: The Remote Control

    FP (ON) turns on the front When Mute is engaged, these panel display backlight and controls display, then adjust the Lexicon logo. the volume from the mute level. When full mute is en- OSD (ON) activates the DC-1 gaged ( Mute), these con- on-screen display.

  • Page 13: Alternate Remote Control Functions Using The

    Installation Lexicon You can access an additional set of controls with the DC-1 remote control by using Alternate Remote Control the Shift key. Functions Using the Shift and Record/Zone 2 buttons...
  • Page 14 Installation DC-1 Version 3 Digital Controller Zone 2 controls are accessed by holding down the Record/Zone 2 button.

  • Page 15: Connection

    The DC-1 may be installed on a shelf or in a standard 19" equipment rack, using an optional rack-mount kit available from Lexicon dealers. Observe the following precautions: • Select a dry, well-ventilated location out of direct sunlight.

  • Page 16: Wiring Considerations

    Installation DC-1 Version 3 Digital Controller Wiring Considerations There is debate over the audible effects of different types of interconnects. Audio/Video Cables Good engineering practices have minimized the effect that cables might have on the inputs and outputs of the DC-1 — but feel free to evaluate different interconnects in your system.
  • Page 17 Installation Lexicon Input sources should be connected directly to the DC-1 inputs. Since TAPE, TUNER and CD are audio only, the video output will default to the video signal from VCR1. This allows TV or other video source viewing while different audio is playing, but can be changed in the INPUT CONFIG menu.

  • Page 18: Ready" Laser Disc And Ld/Dvd Players

    DC-1, an outboard demodulator is required to turn this RF signal back into a digital bitstream. By performing the necessary demodulation outside the DC-1, the potential for RF interference is eliminated. The Lexicon LDD-1 is an excellent example of one such device.

  • Page 19: System Configuration

    System System Configuration Configuration DC-1 Version 3 Digital Controller Restore Factory Defaults Although the DC-1 memory is cleared before it leaves the factory, it is good practice to restore the factory defaults with the following procedure before system configuration. Turn the DC-1 OFF with the remote control. Turn the unit back ON and immediately press and hold the MUTE button on the remote.
  • Page 20 System Configuration Lexicon Bass Tone Control Frequency Response Treble Tone Control Frequency Response Tilt The Tilt parameter can be thought of as a straight line that pivots on a fulcrum at 1kHz to correct the overall tonal balance of source material. The range is -3.0dB to +3.0dB, referenced to the Treble level.

  • Page 21: Display Adjustment

    System Configuration DC-1 Version 3 Digital Controller Display Adjustment Depending on the location of the DC-1 in your room, you may need to adjust the front panel display for optimum viewing. To adjust this display, press or SELECT buttons on the Remote to enter the Main Menu. Press twice to select DISPLAY ADJUST.
  • Page 22 System Configuration Lexicon This menu allows you to choose the position and duration of items dis- played on-screen during normal operation, as well as the options of color or black and white display and conformance to local video format. Adjusting the position allows you to move the DC-1 display items to a location where they will not interfere with any other video overlays or signals your system may generate.

  • Page 23: Input Configuration

    System Configuration DC-1 Version 3 Digital Controller Input Configuration The DC-1 has eight inputs, each of which can be associated with any of the five video and eight digital audio inputs. Selecting Input Configuration from the Setup menu displays a sub-menu which lists these inputs and allows you to select them individually for adjustment.

  • Page 24: Input Effect "Fx" Assignment

    System Configuration Lexicon Input Level Meters When GAIN is selected, two on-screen horizontal bar meters display peak incoming signal level. The highest peak level is shown in dB in a separate text line, and as an arrow in the the meter display. White, yellow and red sections of the bar meter show increasing levels.

  • Page 25: Fx Format

    CONFIG menu. To illustrate how AUTOMATIC would operate with a laser disc player, note the following example which assumes an "AC-3 ready" laser disc player used in conjunction with the Lexicon LDD-1 AC-3/RF Demodulator. This example assumes the V-DISC input has the factory preset configuration shown below, and that the LDD-1 is connected to COAX 2 on the DC-1.
  • Page 26 System Configuration Lexicon The DC-1 V-DISC input is selected. A movie encoded in Dolby Surround is put in the laser disc player and starts to play. The LDD-1 recognizes that the movie is not AC-3 encoded, and automatically routes the laser disc player's PCM (2-channel digital) signal to the DC-1.
  • Page 27 System Configuration DC-1 Version 3 Digital Controller If PCM ONLY is selected as the FX FORMAT for a given input, only PCM PCM Only effects in the DC-1 can be used. When the DC-1 receives a signal which is not PCM encoded, it will mute and display "NO PCM AUDIO."...

  • Page 28: Audio In

    System Configuration Lexicon Audio In This option in the INPUT CONFIG menu determines which audio input connector on the DC-1 rear panel will be used for the MAIN zone. Using the digital inputs will always yield better performance, and these should be used whenever a source component has a digital audio output.

  • Page 29: Record/Zone 2

    System Configuration DC-1 Version 3 Digital Controller Record/Zone 2 The DC-1 is designed to be the control center of any system. As such, there are separate outputs for easy integration of external recording devices as well as an additional “zone” in multi-room installations. The Record and Zone 2 outputs on the DC-1 are wired in parallel so that the input selection will always be the same for both.
  • Page 30 System Configuration Lexicon Zone 2 volume on to the value selected in the OUTPUT LEVELS menu and engages full mute in the main zone. Turns off the Zone 2 outputs, and the associated front panel LEDs. OSD (ON) Displays a STATUS menu for the current input. Press Done to exit.

  • Page 31: Speaker Configuration

    Selections are ENABLE or DISABLE for the se- lected input. The factory default is ENABLE (high) for A/V inputs and DISABLE (low) for audio only inputs. (+5VDC is available via internal jumper. Contact your dealer or Lexicon Customer Service to perform this change.) Speaker The Speaker Configuration menu allows a wide range of choices in speaker type and room setups to provide optimal performance in almost any room.
  • Page 32 System Configuration Lexicon Systems that utilize a full-range center speaker should select LARGE to Center direct center information to the center output with a full frequency re- sponse. Select SMALL for installations where the center speaker is smaller than the left and right front speakers. This will automatically engage the...

  • Page 33: Setting Output Levels

    System Configuration DC-1 Version 3 Digital Controller Subwoofer Output Use of the subwoofer output is specified here. Selecting YES, then pressing SELECT allows you to display and adjust the crossover frequency for the subwoofer output. All summing and filtering is performed in the digital domain.

  • Page 34: Note On External Noise Calibration • Subwoofer

    System Configuration Lexicon The EXTERNAL NOISE TEST loads the Pro Logic, Dolby Digital or DTS Music effect and uses the signal from the currently selected input for calibration. Once a test source is selected, a sub-menu showing each output level is displayed.
  • Page 35 System Configuration DC-1 Version 3 Digital Controller Subwoofer Peak Limiter Dolby Digital (AC-3) and DTS encoded sources can produce low frequency peaks that are much louder than those in matrixed Dolby Surround decod- ing. These higher levels may be troublesome in the home listening environ- ment, either because they disturb non-listeners in nearby rooms, or because of the inability of the subwoofer and its associated amplifier to reproduce these levels without clipping.

  • Page 36: Zone 2 Power On Volume

    System Configuration Lexicon This menu allows you to set the level of attenuation used whenever the Mute Level DC-1 MUTE function is engaged. In the Output Levels menu, attenuation levels of -10dB, -20dB, -30dB, -40dB, and FULL are available. This control in the Output Levels menu allows you to select the volume at Power On Volume which the DC-1 will power on.
  • Page 37 System Configuration DC-1 Version 3 Digital Controller Once you have entered the distance to the nearest speaker, the DC-1 will automatically calculate the maximum allowable distance. The display will show all of the speakers, each with a default distance setting equal to your nearest speaker.
  • Page 38 System Configuration Lexicon SPEAKER ANGLE is the angle between the main speakers as seen from the listen- ing position — here it is about 60°. LIS- TENER POS allows you to adjust for an offset listening position. CAL NOISE is a special digitally generated signal to aid in calibrating the Speaker Angle and Listener Position parameters.
  • Page 39 System Configuration DC-1 Version 3 Digital Controller This control allows you to adjust the left/right balance of the front, side and L/R Balance rear main outputs. This control can also be accessed on the remote by pressing and holding the Shift button and using DONE to move to the left, and SELECT to move to the right.

  • Page 40: Customization

    System Configuration Lexicon Customization After you have calibrated and customized the DC-1, there are two addi- tional steps recommended to safeguard the settings. First, document your adjustments using the table found at the end of this manual. Second, consider locking the settings so that they cannot be inadvertently changed.

  • Page 41: Using Dc-1 Effects

    System Configuration DC-1 Version 3 Digital Controller Using DC-1 Effects When EFFECT ADJUST is selected from the Main menu, the on-screen display shows a list of parameters specific to the current effect, as well as the current value of each parameter. (The front panel display shows one parameter at a time).
  • Page 42 System Configuration Lexicon Restoring the original The RESTORE PARAMETERS function allows you restore the currently selected Effect to its factory preset state. parameter values of an Effect When you select this function, you will be prompted to reconsider erasing your changes. — If you don’t want to erase your versions, press DONE to exit the menu.

  • Page 43: Pcm Effects And Parameters

    PCM Effects and PCM Effects and Parameters Parameters DC-1 Version 3 Digital Controller The PCM effects are compatible with two-channel input signals (analog or digital). These effects are included in both the Dolby Digital and the DTS versions of the DC-1. Panorama Panorama extracts the natural ambience from recorded music and moves it outward from the speakers, producing greater width and depth of image...

  • Page 44: Concert Hall

    PCM Effects and Parameters Lexicon Concert Hall The Concert Hall effect generates the appropriate early reflections for stereo simulation of many different halls, and sends the reflections to all channels in addition to the direct signal in the main speaker. This effect is not appropriate for highly percussive music.

  • Page 45: Party

    PCM Effects and Parameters DC-1 Version 3 Digital Controller Party The Party effect allows unprocessed stereo signals to be played over all speakers for background music or for maximum acoustical output of the system. Parameter Initial Value Range CENTER LEVEL 0-15 SIDE LEVEL +00dB...

  • Page 46: Music Logic

    Logic 7 contains the re-equalizer feature of the THX Cinema effect, as well as Lexicon's proprietary vocal enhancement feature. The combination of stereo surround information during music and decorrelated effects, with discrete steering to the sides and rears, gives Logic 7 unrivaled performance on matrix encoded films.

  • Page 47: Tv Matrix

    This effect provides Dolby Pro Logic Surround decoding designed for any Pro Logic Dolby Surround encoded movies, music, television programs or games. Lexicon's proprietary Auto Azimuth correction makes it one of the most accurate Pro Logic decoders available. Parameter Initial Value...

  • Page 48: Mono Logic

    PCM Effects and Parameters Lexicon Mono Logic Mono Logic takes a monaural soundtrack and sends music and sound effects to the sides and rear through a room simulator mode while keeping the dialog in the center. Parameter Initial Value Range...
  • Page 49 PCM Effects and Parameters DC-1 Version 3 Digital Controller Note that results will vary depending on room acoustics and the low frequency capacity of the surround speakers. As side and/or rear speakers are used for bass enhancement, the effectiveness is improved with speakers capable of reproducing low frequencies (LARGE).
  • Page 50 PCM Effects and Parameters Lexicon LIVENESS adjusts the amount of recirculation within the effect. Higher values mimic more reflective surfaces in the simulated space and increase the amount of time it takes the sound to decay. At very high values, the decay is audibly less smooth than in the Church and Cathedral Effects, which are more effective at simulating very live spaces.
  • Page 51 PCM Effects and Parameters DC-1 Version 3 Digital Controller REAR DELAY OFFSET is an additional delay added to the rear channels. This delay increases the apparent size of the listening space by increasing the rear delay time. Feel free to experiment to find the setting that works best.
  • Page 52 PCM Effects and Parameters Lexicon component of the input to the effect is reduced while the stereo component is increased. If the input signal is pure monaural speech the reverb is almost entirely attenuated. SPEECH DETECT is a real benefit to some popular music (where spoken voice, such as rap, occurs along with the music), stereo television and early stereo movies.

  • Page 53: Effects And Parameters

    AC-3 Effects and AC-3 Effects and Parameters Parameters DC-1 Version 3 Digital Controller AC-3 effects are compatible with Dolby Digital input signals. Any AC-3- capable software and/or source components should be labeled with aDolby Digital badge, similar to the one on the DC-1 front panel. AC-3 Status Display In the AC-3 effects, an AC-3 Status Display is available in the parameter menu with the following information.

  • Page 54: 5.1 2-Channel

    AC-3 Effects and Parameters Lexicon 5.1 2-Channel This effect mixes Dolby Digital 5.1 information for two-channel playback. These soundtracks can be recorded onto two-channel formats, or played back through left and right front speakers. The mix is designed to play back with full surround when decoded through Logic 7.

  • Page 55: Logic 7

    5.1 Logic 7 5.1 Logic 7 combines all the features of Dolby Digital AC-3 with enhance- ments by Lexicon and LucasFilm. This effect uses Logic 7 matrix technology to enhance the steering between the side speakers and the rear speakers, so sounds intended to come from behind the listener actually do come from behind.

  • Page 56: Thx 5.1

    AC-3 Effects and Parameters Lexicon THX 5.1 This effect provides THX 5.1 Cinema enhancements for film soundtracks recorded in the Dolby Digital format. This processing compensates for the acoustical differences between large mixing theaters and the typically smaller home environment. In this effect the side and rear speakers are driven in parallel when you designate side speakers as STANDARD (LARGE or SMALL) in the Speaker Configuration menu.
  • Page 57 AC-3 Effects and Parameters DC-1 Version 3 Digital Controller LFE MIX LEVEL allows separate level attenuation of the LFE channel, which is ultimately mixed to the subwoofer output. As the bass from as many as five other channels is added to the LFE, it can significantly raise subwoofer output levels —...
  • Page 58 AC-3 Effects and Parameters Lexicon...

  • Page 59: Dts Effects And Parameters

    DTS Effects and DTS Effects and Parameters Parameters DC-1 Version 3 Digital Controller DTS effects are compatible with DTS Digital Surround input signals. These effects, along with the PCM Effects described in Chapter 3, and the AC-3 Effects described in Chapter 4, are included in the DTS version of the DC-1.

  • Page 60: Dts Logic 7

    DTS Logic 7 DTS Logic 7 combines all the features of DTS Digital with enhancements by Lexicon and LucasFilm. This effect uses Logic 7 matrix technology to enhance the steering between the side speakers and the rear speakers, so sounds intended to come from behind the listener actually do come from behind.

  • Page 61: Dts Thx 5.1

    DTS Effects and Parameters DC-1 Version 3 Digital Controller DTS THX 5.1 This effect provides THX 5.1 Cinema enhancements for film soundtracks recorded in the DTS format. This processing compensates for the acoustical differences between large mixing theaters and the typically smaller home environment.
  • Page 62 DTS Effects and Parameters Lexicon RE-EQUALIZER equalizes the left, center, and right channel outputs to match the overall frequency balance of the original recording. Without this re-equalization, many films and some television programs will sound too bright. REAR DELAY OFFSET is an additional delay added to the rear channels when listening to LOGIC 7 and MUSIC SURROUND.

  • Page 63: Troubleshooting

    roubleshooting Troubleshooting DC-1 Version 3 Digital Controller Troubleshooting If you encounter a problem, please review the items in the following checklist. Also be sure to thoroughly check all other connected components such as speakers, receiver/amplifier/preamp, VCR, TV, CD player, etc. Problem Possible Cause and Solution Power does not come on...
  • Page 64 If you find that your custom settings are routinely being corrupted, the lithium battery in the DC-1 may need replacing. This part is not field- replaceable — contact your dealer or Lexicon Customer Service. If the unit is still behaving erratically, perform the Restore Defaults procedure described on the following page.

  • Page 65: Routine Maintenance

    DC-1 have now been reset to the values assigned when it cleared final Quality Control at the factory. If you cannot solve functional problems through these procedures, consult your dealer or Lexicon Customer Service. DO NOT OPEN THE UNIT. DOING SO WILL VOID YOUR WARRANTY,...

  • Page 66: Specifications

    pecifications Specifications DC-1 Version 3 Digital Controller Specifications Audio: 8 stereo (RCA) pairs Inputs: Video: 5 composite (RCA), 3 S-Video Digital: 4: 2 coaxial (RCA), 2 optical (TosLink) conforms to IEC-958, S/PDIF standards Audio: 8 outputs:Left, Center, Right, L&R Sides, L&R Rears, Subwoofer (RCA) Outputs: Video: 2 composite (RCA), 2 S-Video...

  • Page 67: Installation Worksheet

    Installation Worksheet Model/Serial #________/____________ Installed by________________________________Phone____________________Date______________ Inputs Gain _______ Name ________________ PCM FX _______ AC-3 FX _______ DTS FX _______ Audio In _______ Video In _______ FX Format: Auto AC-3 Trigger: enabled disabled Rec/Zone2: Analog Digital Blocked Gain _______ Name ________________ PCM FX _______ AC-3 FX _______ DTS FX _______ Audio In _______...
  • Page 68 Lexicon, Inc. 3 Oak Park, Bedford MA 01730-1441 USA Telephone: 781-280-0300 Fax: 781-280-0490 CompuServe: GO LEXICON or 71154,1331@compuserve.com www.lexicon.com Lexicon Part #070-13234 Printed in the United States of America...
