7.3.5 Get System Status

Request to DC-2/MC-1 for it's current system status. DC-2/MC-1 will respond with "System Status
Packet".
7.3.5.1 Command Packet Description
Application Header:
Command DC_CMD_GET_SYS_STATUS
Data Count 0
Application Data:
N/A
7.3.5.2 System Status Response Packet
Application Header:
Command DC_RESP_SYS_STATUS
Data Count 10
Application Data:
Data[0] System Volume
Data[1] Current Input
Data[2] Current EffectId
Data[3] Current Input Sample Rate
Data[4] Current Input Format
Data[5] Mute Active
Data[6] Effect Bypass Active
Data[7] Left/Right Balance
Data[8] Front/Back Balance
Data[9] Video Synch
7.3.5.3 Data Description
System Volume:
Data Type:
Maximum Value:
Conversion:
Current Input:
Data Type:
Definition:
Current EffectId:
Is a null terminated ASCII text string describing the build date and time of the
current ROM. The Format of this text string is:
"yy/mm/dd(sp)hh:mm"
yy- is the last two digits of the year (i.e. year 1999 = 99, year 2000 = 00)
mm - is the month
dd- is the day
(sp) - is an ASCII space character (0x20)
hh - is the hour
mm - is the minute
0x81
0x0A
nn
nn
nn
nn
nn
nn
nn
nn
nn
nn
Unsigned 8 bit integer.
92
0 = -80 dB
92 = +12 dB
Unsigned 8 bit integer.
Appendix D Input Id's
0x16
0x00
