DC-2/MC-1 Serial Communications Protocol

15.5 Examples:

The following examples show the byte's transmitted for the Get Unit Config, Get Effect Definition, and Set Input Name transactions. They are shown as they
should be transmitted from left to right.

15.5.1 Get Unit Configuration

The HOST initiates by sending the GET_UNIT_CONFIG command packet:
SOP DLL DC CMD
F1 03 15
If the command is received with out error the DC-2/MC-1 responds with the UNIT_CONFIG response packet:
SOP DLL DC CMD
F1 1C 80
DATA9 DATA10 DATA11 DATA12
Time Time Time Time
Stamp Stamp Stamp Stamp
39 38 2F 30
9 8 / 0
From the response packet we can see that the DC-2/MC-1 is configured as a
Product Id is Lexicon DC-2/MC-1
Software type DTS
Software level of alpha
Software Version 3.01
Protocol Version 1.00
with 190 system parameters
and 37 effects,
and the ROM was built
"98/06/26 09:59"
AppDC EOP
00 F2
App DC DATA0 DATA1 DATA2
Product SW
Id TYPE SW LVL
19 00 03
DATA13 DATA14 DATA15 DATA16
Time Time Time
Stamp Stamp Stamp Stamp
36 2F 32
6 / 2
Printed on: 10/19/00
DATA3 DATA4 DATA5
SW MJ SW MN PTCL
REV REV MJ REV
03 03 01 01
DATA17 DATA18 DATA19
Time Time Time Time
Stamp Stamp Stamp
36 20 30 39
6 (sp) 0 9
42 of 44
DATA6 DATA7 DATA8
SYS
PTCL PARAM EFFECT
MN REV COUNT COUNT
00 BE 25
DATA20 DATA21 DATA22 DATA23
Time Time Time Time
Stamp Stamp Stamp Stamp
3A 35 39 00
: 5 9
DATA24 EOP
Time
Stamp
00 F2
