DC-2/MC-1 Serial Communications Protocol
Application Header:
Command DC_CMD_GET_REC_STATUS 0x17
Data Count 0
Application Data:
N/A
7.3.6.2 Record/Zone2 Status Response Packet
Application Header:
Command DC_RESP_REC_ZONE2_STATUS 0x82
Data Count 5
Application Data:
Data[0] Zone2 Volume
Data[1] Assigned Input
Data[2] Zone2 Mute Active
Data[3] Record Active
Data[4] Zone2 Balance
7.3.6.3 Data Description
Zone2 Volume:
Data Type:
Maximum Value:
Conversion:
Assigned Input:
Indicates the input that is currently assigned for the record/zone2 outputs.
Data Type:
Definition:
Zone2 Active:
Data Type:
TRUE:
FALSE:
Record Active:
Data Type:
TRUE:
FALSE:
Zone 2 Balance:
Data Type:
Maximum Value:
Conversion:

7.3.7 Get System Parameter Definition

There are two ways to request a DC-2/MC-1 system parameter definition. The first is by Parameter Id and
the second by parameter name. DC-2/MC-1 will respond with "System Parameter Definition Packet".
7.3.7.1 Get System Parameter Definition by Id Command Packet
Error! Not a valid link.
7.3.7.2 Data Description
ParamId:
DataType:
0x00
0x05
nn
nn
nn
nn
nn
Unsigned 8 bit integer.
92
0 = -80 dB
92 = +12 dB
Unsigned 8 bit integer.
Appendix D Input Id's
Boolean.
Zone2 Outputs are active.
Zone2 Outputs are not active.
Boolean.
Digital Record Output is active
Digital Record Output is not Active.
Unsigned 8 bit integer.
32
0 = Left
32 = Right
Unsigned 8 bit integer
