Lexicon, Inc.
DC-2/MC-1 Serial Communications Protocol
Application Header:
Command DC_CMD_GET_INPUT_NAME
Data Count 1
Application Data:
Data[0] InputId
7.3.13.2 Data Description
InputId:
Data Type:
Max Value:
Conversion:
7.3.13.3 Data Validation:
The InputId must be a valid Input number. If it is not the DC-2/MC-1 will respond with a NAK packet and
error code DC_ERR_ INVALID_INPUT_ID.
7.3.13.4 Input Name Response Packet
Application Header:
Command
Data Count
Application Data:
Data[0]
Data[2]- Data[DataCount-1]
7.3.13.5 Data Description
InputId:
Data Type:
Max Value:
Conversion:
InputName:
Data Type:
Max Length:

7.3.14 Get FPD Control Registers

Request to DC-2/MC-1 for FPD control registers. DC-2/MC-1 will respond with "FPD Control Register
Packet".
7.3.14.1 Command Packet Description
Application Header:
Command DC_CMD_GET_FPD_CONTROL
Data Count 0
Application Data:
N/A
7.3.14.2 FPD Control Register Response Packet
Unsigned 8 bit Integer
7
Input Id are defined in Appendix D Input Id's
DC_RESP_INPUT_NAME 0x8A
strlen(InputName) + 2
InputId
InputName
Unsigned 8 bit Integer
7
Input Id's are defined in Appendix D Input Id's
Null(0x00) terminated ASCII character string.
INPUT_NAME_LENGTH defined in Appendix E Protocol Constants.
0x2D
0x01
nn
nn
nn
ch ch ch ... 0x00
0x29
0x00
Printed on: 10/19/00
22 of 44
